Renesas ID82C54
Renesas ID82C54

Renesas ID82C54

Manufacturer No:

ID82C54

Manufacturer:

Renesas

Package:

24-CDIP (0.600, 15.24mm)

Description:

5V Programmable Timer Programmable Timers 82C54 24 Pins 8MHz 5V 24-CDIP (0.600, 15.24mm)

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ID82C54 information

Renesas ID82C54 technical specifications, attributes, parameters and parts with similar specifications to Renesas ID82C54.

  • Type
  • Parameter
  • Factory Lead Time
  • 7 Weeks
  • Mounting Type
  • Through Hole
  • Package / Case
  • 24-CDIP (0.600, 15.24mm)
  • Surface Mount
  • NO
  • Operating Temperature
  • -40°C~85°C
  • Packaging
  • Tube
  • JESD-609 Code
  • e0
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 24
  • ECCN Code
  • EAR99
  • Type
  • Programmable Timer
  • Terminal Finish
  • Tin/Lead (Sn/Pb)
  • HTS Code
  • 8542.39.00.01
  • Technology
  • CMOS
  • Voltage - Supply
  • 4.5V~5.5V
  • Terminal Position
  • DUAL
  • Peak Reflow Temperature (Cel)
  • NOT APPLICABLE
  • Supply Voltage
  • 5V
  • Terminal Pitch
  • 2.54mm
  • Frequency
  • 8MHz
  • Time@Peak Reflow Temperature-Max (s)
  • NOT APPLICABLE
  • Base Part Number
  • 82C54
  • Pin Count
  • 24
  • Qualification Status
  • Not Qualified
  • Number of Bits
  • 16
  • Current - Supply
  • 10mA
  • External Data Bus Width
  • 8
  • Number of Timers
  • 3
  • Information Access Method
  • PARALLEL, DIRECT ADDRESS
  • Height Seated (Max)
  • 5.72mm
  • Width
  • 15.24mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for Renesas ID82C54.

Datasheets:

ConflictMineralStatement:

ID82C54 Overview


There is a 24-CDIP (0.600, 15.24mm) that comes with the timer clock, which is enclosed in the packaging. Frequency 8MHz is set on the programmable timer.It is used to pack in Tube case. Type Through Hole mounting is recommended.Using the programmable timer, a voltage of 4.5V~5.5V can be supplied.The type of chips can be divided into Programmable Timer. The operating temperature of this timer clock is -40°C~85°C. To keep the clock timer's supply current at 10mA. It is based on 82C54. The supply voltage of the programmable timer can rate 5V. The sum of the IC chip pins is 24 . The number of the chip's terminations sums up to 24.
