ICM-20689 Information

TDK ICM-20689 technical specifications, attributes, parameters and parts with similar specifications to TDK ICM-20689.

Type
Parameter

Factory Lead Time
16 Weeks

Mounting Type
Surface Mount

Package / Case
24-VFQFN Module Exposed Pad

Surface Mount
YES

Usage Level
Industrial grade

Operating Temperature
-40°C~85°C TA

Packaging
Tape & Reel (TR)

Published
2014

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Type
Parameter

Number of Terminations
24

Terminal Position
QUAD

Terminal Form
NO LEAD

Number of Functions
1

Supply Voltage
1.8V

Terminal Pitch
0.5mm

JESD-30 Code
S-XQCC-N24

Output Type
I2C, SPI

Supply Voltage-Max (Vsup)
3.45V

Supply Voltage-Min (Vsup)
1.71V

Download datasheets and manufacturer documentation for TDK ICM-20689.

Product Description:

The ICM-20689 is a 6-axis inertial measurement unit (IMU) from TDK InvenSense, designed to provide accurate and reliable motion sensing capabilities. This analog IC is a surface-mount device (SMD) packaged in a 24-VFQFN module with an exposed pad, making it suitable for a wide range of applications.

Features:

6-axis sensing capabilities, including accelerometer, gyroscope, and temperature sensors
I2C and SPI output interfaces for easy integration with various microcontrollers
Operating temperature range of -40°C to 85°C, making it suitable for use in various environments
Supply voltage range of 1.71V to 3.45V, allowing for flexibility in power supply design
Compact package size of 4mm x 4mm x 0.95mm, making it ideal for space-constrained applications

Applications:

Primary applications:
- Consumer electronics, such as smartphones, tablets, and gaming consoles
- Wearable devices, such as smartwatches and fitness trackers
- Automotive systems, including navigation and driver assistance systems
Secondary applications:
- Industrial automation and robotics
- Aerospace and defense systems
- Medical devices and equipment

Alternative Parts:

ICM-20648: A 6-axis IMU with similar features and specifications, but with a different package type
ICM-20648A: A 6-axis IMU with enhanced features and specifications, including higher accuracy and resolution

Embedded Modules:

Various TDK InvenSense modules, such as the ICM-20689-based modules for consumer electronics and automotive applications

FAQs:

Q: What is the operating temperature range of the ICM-20689? A: The operating temperature range of the ICM-20689 is -40°C to 85°C.

Q: What are the output interfaces of the ICM-20689? A: The ICM-20689 has I2C and SPI output interfaces.

Q: What is the supply voltage range of the ICM-20689? A: The supply voltage range of the ICM-20689 is 1.71V to 3.45V.

Q: Is the ICM-20689 RoHS compliant? A: Yes, the ICM-20689 is ROHS3 compliant.

Q: What is the packaging type of the ICM-20689? A: The ICM-20689 is packaged in a tape and reel (TR) format.

Q: What is the moisture sensitivity level (MSL) of the ICM-20689? A: The MSL of the ICM-20689 is 3 (168 hours).
