ADI HMC849ALP4CE

Manufacturer No:

HMC849ALP4CE

Manufacturer:

ADI

Package:

16-VQFN Exposed Pad

Description:

General Purpose RF Type SPDT -40°C~85°C DC~6GHz Isolation:56dB Insertion Loss:1dB 50Ohm IIP3:52dBm 3V~5V

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

HMC849ALP4CE information

ADI HMC849ALP4CE technical specifications, attributes, parameters and parts with similar specifications to ADI HMC849ALP4CE.

Type
Parameter

Lifecycle Status
PRODUCTION (Last Updated: 4 weeks ago)

Factory Lead Time
8 Weeks

Contact Plating
Tin

Mount
Surface Mount

Package / Case
16-VQFN Exposed Pad

Number of Pins
16

Weight
57.09594mg

Operating Temperature
-40°C~85°C

Packaging
Strip

JESD-609 Code
e3

Pbfree Code
no

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

ECCN Code
EAR99

HTS Code
8542.39.00.01

Max Power Dissipation
969mW

Voltage - Supply
3V~5V

Construction
COMPONENT

Frequency
6GHz

Base Part Number
HMC849

Pin Count
16

Circuit
SPDT

Test Frequency
4GHz

Operating Supply Current
1.3mA

Frequency Range
DC~6GHz

RF/Microwave Device Type
DIVERSITY SWITCH

Insertion Loss
1dB

Isolation
56dB

Insertion Loss (dB)
0.9 dB

RF Type
General Purpose

Input Power-Max (CW)
32.99dBm

P1dB
33dBm

IIP3
52dBm

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for ADI HMC849ALP4CE.

HMC849ALP4CE Overview

It is designed to provide optimal performance by utilizing the Strip package.-40°C~85°C should be the operating temperature when RF Switch is operating.In this case, the high power RF switch belongs to the family HMC849.The high power RF switch operation of the system is controlled by 16 pins.RF switch ics operate with 1.3mA supply currents.The RF switch ic type is General Purpose.It is possible for the RF Switch to supply voltages of 3V~5V.

HMC849ALP4CE Features

Strip package
HMC849 family
16 pins
General Purpose RF Type

HMC849ALP4CE Applications

There are a lot of Analog Devices Inc.
HMC849ALP4CE RF Switches applications.

Digital transceiver front end switch
IF switching
Tuner modules
Antenna diversity switching
Cellular/PCS Base Stations
ISM
Wireless Local Loop
Smartphones
Tablets
Mobile devices
