Renesas HIP6521CBZ-T

Manufacturer No:

HIP6521CBZ-T

Manufacturer:

Renesas

Package:

SOIC

Description:

1.27mm PMIC SOIC

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

HIP6521CBZ-T information

Renesas HIP6521CBZ-T technical specifications, attributes, parameters and parts with similar specifications to Renesas HIP6521CBZ-T.

Type
Parameter

Mount
Surface Mount

Package / Case
SOIC

Packaging
Tape & Reel (TR)

Published
2000

JESD-609 Code
e3

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
16

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
70°C

Min Operating Temperature
0°C

Additional Feature
ALSO CONTAINS 3 LINEAR CONTROLLERS

Subcategory
Switching Regulator or Controllers

Technology
CMOS

Terminal Position
DUAL

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Terminal Pitch
1.27mm

Time@Peak Reflow Temperature-Max (s)
40

Pin Count
16

JESD-30 Code
R-PDSO-G16

Number of Outputs
4

Operating Supply Voltage
5V

Input Voltage-Nom
5V

Temperature Grade
COMMERCIAL

Analog IC - Other Type
SWITCHING CONTROLLER

Current - Output
2A

Voltage - Output
4.5V

Control Mode
VOLTAGE-MODE

Frequency - Switching
325kHz

Control Technique
PULSE WIDTH MODULATION

Switcher Configuration
PUSH-PULL

Max Duty Cycle
100 %

Length
9.9mm

Height Seated (Max)
1.75mm

Width
3.9mm

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Renesas HIP6521CBZ-T.

Datasheets:

intersil-hip6521cbzt-datasheets-9993.pdf

HIP6521CBZ-T Overview

It is packaged in SOIC for voltage regulators' voltage regulators' transportation.Ready for shipping in Tape & Reel (TR) package.Voltage regulator supports 4 outputs in total.You can find 16 terminals of the voltage regulator 12v.The pinout of the switching regulator starts from 16 pins it has.When proceeding relow solder, temperature is allowed to peak 260.Other Switching Regulator or Controllers like the voltage regulator DC to DC play a important role in the industry.The IC specialliALSO CONTAINS 3 LINEAR CONTROLLERSes itself in certain areas along with ALSO CONTAINS 3 LINEAR CONTROLLERS.It has a Surface Mount for mouting on PCB or other boards.Temperature lower than 0°C is not suitable for the voltage regulator.Temperature higher than 70°C is not recommended for use.

HIP6521CBZ-T Features

4 outputs
Peak Reflow Temperature: 260
ALSO CONTAINS 3 LINEAR CONTROLLERS

HIP6521CBZ-T Applications

There are a lot of Intersil (Renesas Electronics America)
HIP6521CBZ-T Linear Regulator Controllers applications.

Ultrahigh current ultralow dropout voltage regulator
Constant high-current source
Low parts count 5.0V to 3.3V computer supply
Low noise SMPS post regulator
Low-dropout SMPS post regulator
High-current, current-limited switch
Dual/Triple Power Supplies
Desknotes and Notebooks
Graphic Cards
Ultra-Low-Dropout
