Renesas HIP6006CBZ-T

Manufacturer No:

HIP6006CBZ-T

Manufacturer:

Renesas

Package:

SOIC

Description:

12V 260 Cel DUAL Specialized Voltage Regulator 14 Pins 14 Terminations SOIC

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

HIP6006CBZ-T information

Renesas HIP6006CBZ-T technical specifications, attributes, parameters and parts with similar specifications to Renesas HIP6006CBZ-T.

Type
Parameter

Factory Lead Time
7 Weeks

Mount
Surface Mount

Package / Case
SOIC

Number of Pins
14

Packaging
Cut Tape

Published
1999

JESD-609 Code
e3

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
14

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
70°C

Min Operating Temperature
0°C

Subcategory
Switching Regulator or Controllers

Terminal Position
DUAL

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Frequency
200kHz

Time@Peak Reflow Temperature-Max (s)
30

Pin Count
14

Number of Outputs
1

Qualification Status
Not Qualified

Input Voltage-Nom
12V

Temperature Grade
COMMERCIAL

Analog IC - Other Type
SWITCHING CONTROLLER

Current - Output
500mA

Quiescent Current
50?A

Voltage - Output
12V

Control Mode
VOLTAGE-MODE

Frequency - Switching
1MHz

Control Technique
PULSE WIDTH MODULATION

Switcher Configuration
PUSH-PULL

Max Duty Cycle
100 %

Length
8.65mm

Width
3.9mm

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Renesas HIP6006CBZ-T.

Datasheets:

intersil-hip6006cbzt-datasheets-3544.pdf

HIP6006CBZ-T Overview

The system supports a total of 1 outputs. In order to facilitate transportation, alternator regulator is packaged in SOIC. It's ready to ship in Cut Tape packages. The output voltage of this voltage controller is 12V. The voltage regulator has 14terminals. It has received a great deal of support as a SWITCHING CONTROLLER regulator. The pinout of the rectifier regulator begins with the pins it has at 14. Mounting on PCBs or other boards is easy with the Surface Mount. A power supply regulator with 14pins is present. It is important to note that other Switching Regulator or Controllers in the industry, such as the voltage controller, also play a significant part. The product cannot be used at temperatures below 0°C. A temperature above 70°C is not recommended. It is necessary to have a voltage of 12V for normal operation. The power regulator displays a quiescent current of 50?A. There is a 1MHzswitching frequency on this voltage regulator. There is a range of frequencies 200kHz that this electrical regulator operates on.

HIP6006CBZ-T Features

SWITCHING CONTROLLER analog IC
Supply voltage: 12V
Switching at 1MHz

HIP6006CBZ-T Applications

There are a lot of Intersil (Renesas Electronics America)
HIP6006CBZ-T Specialized Voltage Regulators applications.

LCD-TV/PDP-TV
Copier/Printer
Set-Top Box
DDR Vooo and V? Voltage Generation
PC Dual Power Supply
Server DDR Power
Desktop Computer
Graphics Cards
Cell Phones
Wireless Modems
