Renesas HIP4086ABT

Manufacturer No:

HIP4086ABT

Manufacturer:

Renesas

Package:

SOIC

Description:

Bulk Active EAR99 Gate Drivers ICs 6 SOIC

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

HIP4086ABT information

Renesas HIP4086ABT technical specifications, attributes, parameters and parts with similar specifications to Renesas HIP4086ABT.

Type
Parameter

Factory Lead Time
19 Weeks

Mount
Surface Mount

Package / Case
SOIC

Packaging
Bulk

Published
2010

Part Status
Active

Number of Terminations
24

ECCN Code
EAR99

Max Operating Temperature
125°C

Min Operating Temperature
-40°C

Additional Feature
JUNCTION TEMPERATURE FOR TEST

HTS Code
8542.39.00.01

Technology
MOS

Terminal Position
DUAL

Terminal Form
GULL WING

Number of Functions
3

Reach Compliance Code
unknown

Pin Count
24, 24

JESD-30 Code
R-PDSO-G24

Qualification Status
Not Qualified

Max Output Current
1.5A

Temperature Grade
AUTOMOTIVE

Max Supply Voltage
15V

Min Supply Voltage
7V

Max Supply Current
10.5mA

Current - Output
1.5A

Output Characteristics
TOTEM-POLE

Rise Time
40ns

Fall Time (Typ)
20 ns

Output Polarity
TRUE

Input Characteristics
STANDARD

Interface IC Type
HALF BRIDGE BASED MOSFET DRIVER

Number of Drivers
6

Turn On Time
0.1 ?s

Output Peak Current Limit-Nom
1.7A

High Side Driver
YES

Turn Off Time
0.1 ?s

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for Renesas HIP4086ABT.

Datasheets:

intersil-hip4086abt-datasheets-2564.pdf

HIP4086ABT Overview

For greater flexibility, the SOIC package is adopted.A package of Bulk has been used.This configuration includes 6 drivers.Mosfet driver consists of 24 terminations as Mosfet drivers foundation.The device is mounted using Surface Mount.Its interface IC is HALF BRIDGE BASED MOSFET DRIVER.1.5A is the maximum output current.There are 24, 24 component pins on the board.Mosfet gate drivers is permissible to operate at a temperature of 125°C.Operating temperatures can be as low as -40°C.Mosfet gate drivers is recommended to keep the supply current at 10.5mA to ensure greater stabilMosfet gate driversy.For operation, 15V is the maximum supply voltage.For operation, 7V is the minimum supply voltage.A current of 1.5A is output by the device.The input is characterized by STANDARD.Mosfet gate drivers is also possible to provide JUNCTION TEMPERATURE FOR TEST using unique technologies.
