Renesas HIP4082IB

Manufacturer No:

HIP4082IB

Manufacturer:

Renesas

Package:

SOIC

Description:

Active EAR99 Gate Drivers ICs SOIC

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

HIP4082IB information

Renesas HIP4082IB technical specifications, attributes, parameters and parts with similar specifications to Renesas HIP4082IB.

Type
Parameter

Factory Lead Time
13 Weeks

Mount
Surface Mount

Package / Case
SOIC

Number of Pins
16

Published
1994

JESD-609 Code
e0

Pbfree Code
no

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
16

ECCN Code
EAR99

Terminal Finish
Tin/Lead (Sn/Pb)

Max Operating Temperature
125°C

Min Operating Temperature
-55°C

Technology
MOS

Terminal Position
DUAL

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
245

Number of Functions
1

Supply Voltage
12V

Terminal Pitch
1.27mm

Reach Compliance Code
not_compliant

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Pin Count
16

Qualification Status
Not Qualified

Max Output Current
1.25A

Temperature Grade
MILITARY

Max Supply Voltage
15V

Min Supply Voltage
8.5V

Nominal Supply Current
2.6mA

Max Supply Current
6.4mA

Current - Output
1.25A

Voltage - Output
1.3V

Rise Time
9ns

Fall Time (Typ)
9 ns

Interface IC Type
FULL BRIDGE BASED MOSFET DRIVER

Turn On Time
0.11 ?s

Output Peak Current Limit-Nom
1.4A

High Side Driver
YES

Turn Off Time
0.08 ?s

Length
9.9mm

Height Seated (Max)
1.75mm

Width
3.9mm

REACH SVHC
No SVHC

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for Renesas HIP4082IB.

Datasheets:

intersil-hip4082ib-datasheets-2226.pdf

HIP4082IB Overview

The SOIC package provides greater flexibility.Initially, the configuration is composed of 16 terminations.Mounting the device requires Surface Mount.During design, it is configured with 16 pins.A supply voltage of 12V is required for operation.The interface IC of the device is FULL BRIDGE BASED MOSFET DRIVER.Mosfet driver is possible for the output current to be as low as 1.25A.A total of 16 pins are available for component connections.The basis has 4 integrated outputs.Temperatures greater than 125°C are not allowed.Mosfet gate drivers is permissible to operate at a temperature of -55°C.If you want a stable supply current, you should keep it at 6.4mA.In order for the device to operate, the supply voltage must be 15V.Its minimum operating voltage is 8.5V.1.25A is the output current.The output voltage is 1.3V.

HIP4082IB Features

16 pins

HIP4082IB Applications

There are a lot of Intersil (Renesas Electronics America)
HIP4082IB gate drivers applications.

A/D drivers
Line drivers
Portable computers
High-speed communications
RGB applications
Broadcast equipment
Active filtering
Head-up and Head mounted displays
High current laser/LED systems
LCD/LCoS/DLP portable and embedded pico projectors
