Renesas HIP4080AIBZ

Manufacturer No:

HIP4080AIBZ

Manufacturer:

Renesas

Package:

SOIC

Description:

Bulk Active EAR99 Gate Drivers ICs 4 SOIC

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

HIP4080AIBZ information

Renesas HIP4080AIBZ technical specifications, attributes, parameters and parts with similar specifications to Renesas HIP4080AIBZ.

Type
Parameter

Factory Lead Time
9 Weeks

Mount
Surface Mount

Package / Case
SOIC

Number of Pins
20

Packaging
Bulk

Published
1993

JESD-609 Code
e3

Part Status
Active

Moisture Sensitivity Level (MSL)
2 (1 Year)

Number of Terminations
20

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Terminal Position
DUAL

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Supply Voltage
12V

Terminal Pitch
1.27mm

Time@Peak Reflow Temperature-Max (s)
30

Qualification Status
Not Qualified

Max Output Current
2.5A

Temperature Grade
INDUSTRIAL

Min Supply Voltage
9.5V

Power Dissipation-Max
470mW

Nominal Supply Current
1.25mA

Max Supply Current
15mA

Current - Output
2.6A

Frequency - Switching
1MHz

Rise Time
10ns

Fall Time (Typ)
10 ns

Interface IC Type
FULL BRIDGE BASED MOSFET DRIVER

Number of Drivers
4

Output Peak Current Limit-Nom
1.4A

High Side Driver
YES

Turn Off Time
0.11 µs

Height
2.35mm

Length
13mm

Width
7.6mm

REACH SVHC
No SVHC

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Renesas HIP4080AIBZ.

Datasheets:

intersil-hip4080aibz-datasheets-1926.pdf

HIP4080AIBZ Overview

Gate drivers provides greater flexibilGate driversy to use the SOIC package.Gate drivers is package in Bulk case.There are 4 drivers installed for this device.20 terminations constitute its foundation.Mosfet driver is mounted using the Surface Mount method.A total of 20 pins are available on the device.In addition, it is specifically designed to operate with a supply voltage of 12V.The interface chip of the system is FULL BRIDGE BASED MOSFET DRIVER.There is an output current limit of 2.5A for this device.There is a maximum acceptable operating temperature of 85°C.Temperatures below -40°C are allowed as the minimum.In order to ensure greater stability, it is recommended to keep the supply current at 15mA.This device operates at its maximum voltage of 95V.A minimum supply voltage of 9.5V is required for operation.Mosfet gate drivers is outputting a current of 2.6A.

HIP4080AIBZ Features

Embedded in the Bulk package
4 drivers
20 pins

HIP4080AIBZ Applications

There are a lot of Intersil (Renesas Electronics America)
HIP4080AIBZ gate drivers applications.

Video amplifiers
PCMCIA applications
A/D drivers
Line drivers
Portable computers
High-speed communications
RGB applications
Broadcast equipment
Active filtering
Head-up and Head mounted displays
