Manufacturer No:

HEF4094BT

Manufacturer:

NEXPERIA

Package:

SOIC

Description:

8 Bit Shift Register 16 Pin 5V SOIC

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

HEF4094BT information

NEXPERIA HEF4094BT technical specifications, attributes, parameters and parts with similar specifications to NEXPERIA HEF4094BT.

  • Type
  • Parameter
  • Package / Case
  • SOIC
  • Surface Mount
  • YES
  • Number of Pins
  • 16
  • Published
  • 2013
  • JESD-609 Code
  • e4
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 16
  • Terminal Finish
  • Nickel/Palladium/Gold (Ni/Pd/Au)
  • Max Operating Temperature
  • 70°C
  • Min Operating Temperature
  • -40°C
  • Additional Feature
  • PARALLEL OUTPUT IS LATCHED; UNLATCHED SERIAL SHIFT RIGHT OUTPUT
  • Technology
  • CMOS
  • Terminal Position
  • DUAL
  • Terminal Form
  • GULL WING
  • Peak Reflow Temperature (Cel)
  • 260
  • Number of Functions
  • 1
  • Supply Voltage
  • 5V
  • Frequency
  • 28MHz
  • Time@Peak Reflow Temperature-Max (s)
  • 30
  • Number of Elements
  • 1
  • Temperature Grade
  • AUTOMOTIVE
  • Voltage
  • 15V
  • Max Supply Voltage
  • 15.5V
  • Number of Bits
  • 8
  • Logic Function
  • Shift Register
  • Output Characteristics
  • 3-STATE
  • Output Polarity
  • TRUE
  • Logic IC Type
  • SERIAL IN PARALLEL OUT
  • Trigger Type
  • POSITIVE EDGE
  • Propagation Delay (tpd)
  • 330 ns
  • Count Direction
  • RIGHT
  • Length
  • 9.9mm
  • Width
  • 3.9mm
  • REACH SVHC
  • No SVHC
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for NEXPERIA HEF4094BT.

RohsStatement:

Datasheets:

HEF4094BT Overview


There is a SOIC package embedded with the device. Chip terminations add up to 16. Voltage rating of the part is 5V. 1 elements are present in this part. In this device, there are 16 pins. The following additional elements are important to note: PARALLEL OUTPUT IS LATCHED; UNLATCHED SERIAL SHIFT RIGHT OUTPUT. IC chip bits total 8. The product should be used at temperatures below 70°C. Operation of this device requires a value greater than -40°C. It is employed under the condition of 15.5V. Voltages higher than 4.5V are used for this supply. Its frequency is set to 28MHz.

HEF4094BT Features


With 16 pins


HEF4094BT Applications


There are a lot of Nexperia
HEF4094BT Shift Registers applications.


  • store data in digital form
  • ROM Chips
  • Flash Memory
  • Cache memory in CPU
  • Data Format Converters
  • Data Processors
  • Pseudo Random Pattern Generator
  • Pulse Extenders
  • Pattern Recognizers
  • Interconnectors
