NEXPERIA HEF4040BT

Manufacturer No:

HEF4040BT

Manufacturer:

NEXPERIA

Package:

SOP-16

Description:

Binary Counter

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

HEF4040BT information

NEXPERIA HEF4040BT technical specifications, attributes, parameters and parts with similar specifications to NEXPERIA HEF4040BT.

Type
Parameter

RoHS Status
RoHS Compliant

Part Life Cycle Code
Active

Ihs Manufacturer
NEXPERIA

Package Description
SOP-16

Reach Compliance Code
compliant

ECCN Code
EAR99

HTS Code
8542.39.00.01

Date Of Intro
1985-01-15

Samacsys Manufacturer
Nexperia

Count Direction
UP

Family
4000/14000/40000

JESD-30 Code
R-PDSO-G16

JESD-609 Code
e4

Length
9.9 mm

Load Capacitance (CL)
50 pF

Load/Preset Input
YES

Logic IC Type
BINARY COUNTER

Max Frequency@Nom-Sup
10000000 Hz

Mode of Operation
ASYNCHRONOUS

Moisture Sensitivity Level
1

Number of Bits
12

Number of Functions
1

Number of Terminals
16

Operating Temperature-Max
85 °C

Package Body Material
PLASTIC/EPOXY

Package Code
SOP

Package Equivalence Code
SOP16,.25

Package Shape
RECTANGULAR

Package Style
SMALL OUTLINE

Peak Reflow Temperature (Cel)
260

Power Supply Current-Max (ICC)
50 mA

Prop. Delay@Nom-Sup
210 ns

Propagation Delay (tpd)
210 ns

Seated Height-Max
1.75 mm

Supply Voltage-Max (Vsup)
15 V

Supply Voltage-Min (Vsup)
3 V

Supply Voltage-Nom (Vsup)
5 V

Surface Mount
YES

Technology
CMOS

Temperature Grade
INDUSTRIAL

Terminal Finish
NICKEL PALLADIUM GOLD

Terminal Form
GULL WING

Terminal Pitch
1.27 mm

Terminal Position
DUAL

Time@Peak Reflow Temperature-Max (s)
30

Trigger Type
NEGATIVE EDGE

Width
3.9 mm

Download datasheets and manufacturer documentation for NEXPERIA HEF4040BT.

Datasheets:

NEXP-S-A0014031197-1.pdf

HEF4040BT Overview

A SOICpackage is used for this device. Using 16terminations, it can be configured. 5Vis fully flexible due to its voltage supply. The device contains 1terminations. As a result, it is packaged in the way of a Cut Tape. Circuit components are connected with 16pins. The device is mounted in the direction of [0]. The device stores 12bits of information. A temperature grade of INDUSTRIALis specified for this device. This device operates at 70°C°C for extended periods of time with acceptable electrical stability. Temperature ranges are specified, with -40°Cset as a lower limit. Frequency 50MHzdetermines its operation. It reaches 15.5Vvoltage at its maximum. The device can operate at as low a voltage as 4.5V.
