Manufacturer No:

HDG204-DN-3

Manufacturer:

H&D Wireless AB

Package:

44-TQFN Exposed Pad Module

Description:

TxRx Only 2.4GHz~2.5GHz 3.3V SPI 54Mbps 60mA - Receiving 15mA - Transmitting 16QAM, 64QAM, BPSK, CCK, DBPSK, DQPSK, OFDM 2 44-TQFN Exposed Pad Module

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

HDG204-DN-3 information

H&D Wireless AB HDG204-DN-3 technical specifications, attributes, parameters and parts with similar specifications to H&D Wireless AB HDG204-DN-3.

  • Type
  • Parameter
  • Factory Lead Time
  • 14 Weeks
  • Mount
  • Surface Mount
  • Package / Case
  • 44-TQFN Exposed Pad Module
  • Number of Pins
  • 44
  • Supplier Device Package
  • 44-QFN SIP (8x8)
  • Operating Temperature
  • -40°C~85°C
  • Packaging
  • Tray
  • Published
  • 2003
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 3 (168 Hours)
  • Type
  • TxRx Only
  • Max Operating Temperature
  • 85°C
  • Min Operating Temperature
  • -40°C
  • Voltage - Supply
  • 3.3V
  • Depth
  • 8mm
  • Frequency
  • 2.4GHz~2.5GHz
  • Interface
  • SPI
  • Protocol
  • 802.11b/g
  • Power - Output
  • 18dBm
  • RF Family/Standard
  • WiFi
  • Sensitivity
  • -96dBm
  • Data Rate (Max)
  • 54Mbps
  • Serial Interfaces
  • SPI
  • Current - Receiving
  • 60mA
  • Modulation
  • 16QAM, 64QAM, BPSK, CCK, DBPSK, DQPSK, OFDM
  • Sensitivity (dBm)
  • -96 dBm
  • Number of GPIO
  • 2
  • GPIO
  • 2
  • Length
  • 8mm
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for H&D Wireless AB HDG204-DN-3.

Datasheets:

HDG204-DN-3 Overview


As a result of RF transceiver IC's 44-TQFN Exposed Pad Module package, it helps to save board space on the board. With transceiver RF's high efficiency, transceiver RF emerges as a TxRx Only.Using advanced packaging techniques Tray, high reliability is ensured.On this transceiver RF circuit board, there are 44 pins.The transceiver is mounted by a Surface Mount-axis.Using the frequency of 2.4GHz~2.5GHz, RF transceiver operates .
