LATTICE GAL16V8D-10LJN

Manufacturer No:

GAL16V8D-10LJN

Manufacturer:

LATTICE

Package:

LEAD FREE, PLASTIC, LCC-20

Description:

Description: EE PLD, 10ns, PAL-Type, CMOS, PQCC20, LEAD FREE, PLASTIC, LCC-20

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

GAL16V8D-10LJN information

LATTICE GAL16V8D-10LJN technical specifications, attributes, parameters and parts with similar specifications to LATTICE GAL16V8D-10LJN.

Type
Parameter

Pbfree Code
Yes

RoHS Status
RoHS Compliant

Part Life Cycle Code
Obsolete

Ihs Manufacturer
LATTICE SEMICONDUCTOR CORP

Part Package Code
QLCC

Package Description
LEAD FREE, PLASTIC, LCC-20

Pin Count
20

Reach Compliance Code
unknown

ECCN Code
EAR99

HTS Code
8542.39.00.01

Samacsys Manufacturer
Lattice Semiconductor

Architecture
PAL-TYPE

Clock Frequency-Max
66.7 MHz

JESD-30 Code
S-PQCC-J20

JESD-609 Code
e3

Length
8.9662 mm

Moisture Sensitivity Level
1

Number of Dedicated Inputs
8

Number of I/O Lines
8

Number of Inputs
18

Number of Outputs
8

Number of Product Terms
64

Number of Terminals
20

Operating Temperature-Max
70 °C

Output Function
MACROCELL

Package Body Material
PLASTIC/EPOXY

Package Code
QCCJ

Package Equivalence Code
LDCC20,.4SQ

Package Shape
SQUARE

Package Style
CHIP CARRIER

Peak Reflow Temperature (Cel)
250

Programmable Logic Type
EE PLD

Propagation Delay
10 ns

Qualification Status
Not Qualified

Seated Height-Max
4.572 mm

Supply Voltage-Max
5.25 V

Supply Voltage-Min
4.75 V

Supply Voltage-Nom
5 V

Surface Mount
YES

Technology
CMOS

Temperature Grade
COMMERCIAL

Terminal Finish
Matte Tin (Sn)

Terminal Form
J BEND

Terminal Pitch
1.27 mm

Terminal Position
QUAD

Time@Peak Reflow Temperature-Max (s)
40

Width
8.9662 mm

Download datasheets and manufacturer documentation for LATTICE GAL16V8D-10LJN.

Datasheets:

LATTS01742-1.pdf

GAL16V8D-10LJN Overview

This network has 8macro cells, which are cells that provide radio coverage provided by a high-power cell site (tower, antenna, mast).You can find it in package 20-LCC (J-Lead).20 terminations have been programmed into the device.Its terminal position is QUAD.It is powered by a voltage of 5V volts.Package the chip by Bulk.In order to ensure the reliability of the device, it is designed to operate at a temperature of [0].Chips should be mounted by Surface Mount.In terms of FPGAs, it belongs to the GAL®16V8 series.It has 20 pins programmed.Its related parts can be found in the [0].It is recommended that the supply voltage be kept at 5Vto maximize efficiency.The electronic component is mounted by Surface Mount.There are 20 pins on the device.In this case, the maximum supply voltage is 5.25V.Despite its minimal supply voltage of 4.75V, it is capable of operating.A total of 5V power supplies are needed to run it.In this case, 83.3MHz is the frequency that can be achieved.Input signals are detected by 8 dedicated inputs.The output is configured with the value 8.In addition, it contains 64 product terms.

GAL16V8D-10LJN Features

20-LCC (J-Lead) package
The operating temperature of 0°C~75°C TA
20 pin count
20 pins
5V power supplies
8 outputs

GAL16V8D-10LJN Applications

There are a lot of Lattice Semiconductor Corporation
GAL16V8D-10LJN CPLDs applications.

Discrete logic functions
Bootloaders for FPGAs
Address decoders
Custom state machines
Digital systems
Portable digital devices
Handheld digital devices
Battery operated portable devices
Complex programmable logic devices
Digital designs
