OMRON G2R-2A-H-DC24

Manufacturer No:

G2R-2A-H-DC24

Manufacturer:

OMRON

Package:

Description:

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

G2R-2A-H-DC24 information

OMRON G2R-2A-H-DC24 technical specifications, attributes, parameters and parts with similar specifications to OMRON G2R-2A-H-DC24.

Type
Parameter

Factory Lead Time
10 Weeks

Contact Material
Silver

Mount
Through Hole

Number of Pins
6

Published
2002

Pbfree Code
yes

Number of Terminations
6

Termination
PC Pin

ECCN Code
EAR99

Max Operating Temperature
70°C

Min Operating Temperature
-40°C

Reference Standard
CSA; SEMKO; TUV; UL; VDE

Physical Dimension
29mm x 13mm x 25.5mm

Contact Resistance
50mOhm

Insulation Resistance
1000000000Ohm

Max Voltage Rating (AC)
380V

Electrical Life
100000 Cycle(s)

Throw Configuration
DPST

Max Voltage Rating (DC)
125V

Relay Type
General Purpose

Coil Resistance
1.6kOhm

Contact (AC) Max Rating R Load
3A@250VAC

Operate Time
15 ms

Coil Voltage
24V

Coil Current
15mA

Release Time
5 ms

Contact (DC) Max Rating R Load
3A@30VDC

Contact Rating (Current)
3A

Power Consumption
360mW

Coil Power
360mW

Contact/Output Supply Type
AC/DC

Relay Action
MOMENTARY

Coil Voltage (DC)
24V

Coil/Input Supply Type
DC

Current Rating (Max)
3A

Dielectric Strength Between Open Contacts
1000 Vrms

Input Switching Control Type
Random

Dielectric Strength Between Coil and Contacts
5000 Vrms

Relay Form
1 FORM C

Height
25.5mm

Length
29mm

Width
13mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for OMRON G2R-2A-H-DC24.

Datasheets:

omron-g2r2ahdc24-datasheets-9755.pdf
