HIROSE FX8C-120S-SV(92)

Manufacturer No:

FX8C-120S-SV(92)

Manufacturer:

Package:

Description:

Receptacle, Center Strip Contacts Tape & Reel (TR) 2 Rows 0.024 0.60mm Surface Mount 120 Positions FunctionMax? FX8C Gold Solder COPPER ALLOY

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

FX8C-120S-SV(92) information

HIROSE FX8C-120S-SV(92) technical specifications, attributes, parameters and parts with similar specifications to HIROSE FX8C-120S-SV(92).

Type
Parameter

Factory Lead Time
10 Weeks

Contact Material
COPPER ALLOY

Mount
Surface Mount

Mounting Type
Surface Mount

Packaging
Tape & Reel (TR)

Series
FunctionMax? FX8C

Published
2010

JESD-609 Code
e3

Feature
Board Guide

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Termination
Solder

Connector Type
Receptacle, Center Strip Contacts

Number of Positions
120

Number of Rows
2

MIL Conformance
NO

DIN Conformance
NO

IEC Conformance
NO

Filter Feature
NO

Mixed Contacts
NO

Option
GENERAL PURPOSE

Pitch
0.024 0.60mm

Total Number of Contacts
120

Mating Information
MULTIPLE MATING PARTS AVAILABLE

Contact Gender
FEMALE

UL Flammability Code
94V-0

Height Above Board
0.156 3.96mm

Stack Height (Mating)
5mm 6mm 7mm 9mm 11mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for HIROSE FX8C-120S-SV(92).

Datasheets:

hiroseelectriccoltd-fx8c60ssv71-datasheets-8440.pdf

PCN Assembly/Origin:

hiroseelectriccoltd-tm4dc1-pcnassemblyorigin-1202.pdf

FX8C-120S-SV(92) Overview

Packaging is in the form of Receptacle, Center Strip Contacts.An orange Tape & Reel (TR) case is used to package the product.This device has a Surface Mount mounting type.Specifically, it is one of the products in the FunctionMax? FX8C Series.In operation, Board Guide can be maintained as long as Board Guide is unchanged.A Surface Mount socket is required for the mounting of this part.
