FTDI FT4232H MINI MODULE

Manufacturer No:

FT4232H MINI MODULE

Manufacturer:

FTDI

Package:

Description:

USB HI-SPEED FT4232H EVALUATION USB to quad channel serial/MPSSE/FIFO Development Module

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

FT4232H MINI MODULE information

FTDI FT4232H MINI MODULE technical specifications, attributes, parameters and parts with similar specifications to FTDI FT4232H MINI MODULE.

Type
Parameter

Data Rates
12Mbaud

Interfaces
MPSSE

USB Connector
Mini B

Packages
N/A

Channels
4

I/O Connector
Two 26-pin, 0.1” dual-row headers

I/O Voltage
3.3V

USB Class
FTDI Drivers

Virtual Com Port
Yes

FTDI Internal IC
FT4232H

Download datasheets and manufacturer documentation for FTDI FT4232H MINI MODULE.

Datasheet:

7cd81ef13473b86a9d8d1155d882bc89.pdf

The FT4232H is FTDI’s 5th generation of USB devices. The FT4232H is a USB 2.0 Hi-Speed (480Mb/s) to UART IC. It has the capability of being configured in a variety of industry standard serial or parallel interfaces.

The FT4232H features 4 UARTs. Two of these have an option to independently configure an MPSSE engine, this allows the FT4232H to operate as two UART/Bit-Bang ports plus two MPSSE engines used to emulate JTAG, SPI, I2C, Bit-bang or other synchronous serial modes.

The FT4232H is available in Pb-free (RoHS compliant) 64-pin LQFP/QFN and 56-pin VQFN packages.

User Guide
