Manufacturer No:

FSUSB42UMX

Manufacturer:

ONSEMI

Package:

10-UFQFN

Description:

Low Power, Two-Port, Hi-Speed USB2.0 (480Mbps) Switch

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

FSUSB42UMX information

ONSEMI FSUSB42UMX technical specifications, attributes, parameters and parts with similar specifications to ONSEMI FSUSB42UMX.

  • Type
  • Parameter
  • VCC Max (V)
  • 4.4
  • MSL Type
  • 1
  • Number of Switches
  • 2
  • Configuration
  • DPDT
  • Icc Max (µA)
  • 1
  • ron Max (Ω)
  • 6.5
  • VCC Min (V)
  • 2.4
  • Package Type
  • UQFN-10
  • Case Outline
  • 523BC
  • MSL Temp (°C)
  • 260
  • Container Type
  • REEL
  • Container Qty.
  • 5000
  • Channels
  • 2

Download datasheets and manufacturer documentation for ONSEMI FSUSB42UMX.

Package Drawing:

Datasheet:

The FSUSB42 is a bi-directional, low-power, two-port, Hi-Speed, USB2.0 switch. Configured as a double-pole, double-throw switch (DPDT) switch, it is optimized for switching between two Hi-Speed (480Mbps) sources or a Hi-Speed and Full-Speed (12Mbps) source. The FSUSB42 is compatible with the requirements of USB2.0 and features an extremely low on capacitance (CON) of 5.5pF. The wide bandwidth of this device (720MHz) exceeds the bandwidth needed to pass the third harmonic, resulting in signals with minimum edge and phase distortion. Superior channel-to-channel crosstalk also minimizes interference. The FSUSB42 contains special circuitry on the switch I/O pins for applications where the VCC supply is powered-off (VCC=0), which allows the device to withstand an over-voltage condition. This device is designed to minimize current consumption even when the control voltage applied to the SEL pin is lower than the supply voltage (VCC). This feature is especially valuable to ultra-portable applications, such as cell phones, allowing for direct interface with the generalpurpose I/Os of the baseband processor. Other applications include switching and connector sharing in portable cell phones, PDAs, digital cameras, printers, and notebook computers.

Application

  • Media Tablets
  • Storage & Peripherals
  • Mobile Handsets
  • Wireless LAN Card & Broadband Access
  • PMP/MP3 Players

Feature

  • Low On Capacitance: 3.7pF Typical
  • Low On Resistance: 3.9Ω Typical
  • Low Power Consumption: 1µA Maximum
  • 15µA Maximum ICCT over and Expanded Control Voltage Range (VIN= 1.8V, VCC= 4.3V)
  • Wide -3dB Bandwitch: > 720MHz
  • Packaged in:
  • 10-Lead UMLP (1.4 x 1.8mm)
  • 10-Lead MSOP
  • 8kV ESD Rating, >16kV Power/GND ESD Rating
  • Over-Voltage Tolerance (OVT) on all USB Ports Up to 5.25V without External Components
