ONSEMI FSQ0765RQLDTU

Manufacturer No:

FSQ0765RQLDTU

Manufacturer:

ONSEMI

Package:

TO-220-6 Full Pack, Formed Leads

Description:

6 Terminations 8V~20V 6 Pin FSQ0765 AC to DC power converter FPS? Series 1 Outputs 48kHz~67kHz

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

FSQ0765RQLDTU information

ONSEMI FSQ0765RQLDTU technical specifications, attributes, parameters and parts with similar specifications to ONSEMI FSQ0765RQLDTU.

Type
Parameter

Mount
Through Hole

Mounting Type
Through Hole

Package / Case
TO-220-6 Full Pack, Formed Leads

Number of Pins
6

Weight
3.006g

Operating Temperature
-25°C~85°C TA

Packaging
Tube

Series
FPS?

JESD-609 Code
e3

Pbfree Code
yes

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
6

ECCN Code
EAR99

Resistance
1.6Ohm

Terminal Finish
Tin (Sn)

Subcategory
Switching Regulator or Controllers

Power Rating
70W

Max Power Dissipation
90W

Terminal Position
ZIG-ZAG

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Base Part Number
FSQ0765

Number of Outputs
1

Operating Supply Voltage
26V

Current
3A

Voltage - Supply (Vcc/Vdd)
8V~20V

Max Supply Current
5mA

Turn On Delay Time
27 ns

Topology
Flyback

Control Mode
CURRENT-MODE

Frequency - Switching
48kHz~67kHz

Turn-Off Delay Time
63 ns

Max Output Power
70W

Internal Switch(s)
Yes

Max Duty Cycle
50 %

Output Isolation
Isolated

Voltage - Start Up
12V

Min Breakdown Voltage
650V

Height
16.07mm

Length
10.36mm

Width
4.8mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for ONSEMI FSQ0765RQLDTU.

FSQ0765RQLDTU Overview

There is a ac to dc converter embedded in package TO-220-6 Full Pack, Formed Leads .The ac dc converter is available in Tube case.In this case, the AC/DC converter is mounted in the way of Through Hole .This ac dc converter should be operated at a temperature of -25°C~85°C TA °C so that it can deliver its performance.When the switching frequency reaches 48kHz~67kHz , the process is complete.The AC/DC converter is capable of being used when the supply voltage is 8V~20V (Vcc/Vdd).There are a total of 6 terminations in it.It contains 6 pins.Through Hole is a suitable mounting point for the ac dc converters.It belongs to a manufacturer family of FPS? .Similar acdc converters can be found using the FSQ0765 family.AC to DC converter is necessary to run 1 outputs.AC to DC converter is contained in Switching Regulator or Controllers .Interfacing ICs conduct when there is 26V supply voltage.Approximately 5mA amps of supply current can be handled by the power AC DC.It can be determined that the resistance of this power AC DC is 1.6Ohm .A maximum output power of 70W can be used with the AC to DC power converter.

FSQ0765RQLDTU Features

Packaged with TO-220-6 Full Pack, Formed Leads
Switching Frequency at 48kHz~67kHz
With 6 pins
Operating Supply Voltage at the range of 26V
Resistance : 1.6Ohm

FSQ0765RQLDTU Applications

There are a lot of ON Semiconductor
FSQ0765RQLDTU AC DC Converters applications.

DVD players
Records
Linear Adapter Replacements
Chargers for cell/cordless phones
PDAs
MP3
Portable audio
Adapters
Networking
Battery Chargers
