ONSEMI FSFR1700

Manufacturer No:

FSFR1700

Manufacturer:

ONSEMI

Package:

10-SIP Module, 9 Leads, Formed Leads

Description:

9 Terminations 11.3V~25V 9 Pin FSFR1700 AC to DC power converter FSFR Series 1 Outputs Up to 300kHz

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

FSFR1700 information

ONSEMI FSFR1700 technical specifications, attributes, parameters and parts with similar specifications to ONSEMI FSFR1700.

Type
Parameter

Lifecycle Status
ACTIVE, NOT REC (Last Updated: 1 week ago)

Factory Lead Time
5 Weeks

Mount
Through Hole

Mounting Type
Through Hole

Package / Case
10-SIP Module, 9 Leads, Formed Leads

Number of Pins
9

Weight
3.708632g

Operating Temperature
-40°C~130°C TJ

Packaging
Tube

Series
FSFR

JESD-609 Code
e3

Pbfree Code
yes

Part Status
Not For New Designs

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
9

Resistance
1.25Ohm

Terminal Finish
Tin (Sn)

Power (Watts)
200W

Max Power Dissipation
11.6W

Terminal Position
ZIG-ZAG

Number of Functions
1

Supply Voltage
7.5V

Base Part Number
FSFR1700

Number of Outputs
1

Operating Supply Voltage
12.5V

Nominal Supply Current
7mA

Power Dissipation
11.6W

Output Current
6A

Voltage - Supply (Vcc/Vdd)
11.3V~25V

Max Supply Current
9mA

Output Power
100W

Control Features
EN, Frequency Control

Topology
Half-Bridge

Frequency - Switching
Up to 300kHz

Nominal Input Voltage
25V

Internal Switch(s)
Yes

Fault Protection
Current Limiting, Over Load, Over Temperature, Over Voltage

Max Duty Cycle
52 %

Duty Cycle
50%

Built-in Protections
OVER CURRENT; OVER VOLTAGE; THERMAL

Output Isolation
Isolated

Voltage - Breakdown
500V

Voltage - Start Up
14.5V

Length
26mm

Width
3.2mm

REACH SVHC
No SVHC

Radiation Hardening
No

Download datasheets and manufacturer documentation for ONSEMI FSFR1700.

PCN Design/Specification:

onsemiconductor-lvkit-pcndesignspecification-5808.pdf

PCN Packaging:

onsemiconductor-lvkit-pcnpackaging-5809.pdf

FSFR1700 Overview

This ac to dc converter is embedded in package 10-SIP Module, 9 Leads, Formed Leads .The AC/DC power converter is available in Tube .There is a AC/DC converter mounted in the way of Through Hole .For the ac dc converter to perform properly, it should be operated at a temperature of -40°C~130°C TJ °C.Up to 300kHz is the switching frequency.As long as the supply voltage (Vcc/Vdd) is within the range of 11.3V~25V , the AC/DC converter may be used.In total, there are 9 terminations.The ac/dc converter has a total of 9 pins.Through Hole are the recommended mounting method for the ac dc converters.This AC to DC converter belongs to the FSFR manufacturer family.A similar acdc converter can be searched by using the FSFR1700 family.A total of 1 outputs are to be processed.In this AC to DC transformer, the output current is set to 6A .There is 24V voltage output from it.It is possible to read the REACH SVHC standard at: No SVHC .A coverter produces 100W watts of output power.As soon as the supply voltage drops to 12.5V , the interface IC conducts.The maximum supply current is 9mA .You should always set this AC to DC converter to 7.5V .It is possible to determine the resistance of this power AC DC to be 1.25Ohm .
