Manufacturer No:

FSA2269UMX

Manufacturer:

ONSEMI

Package:

10-UFQFN

Description:

10 Termination Analog Switch FSA2269 10 Pin 2.3V 10-UFQFN

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

FSA2269UMX information

ONSEMI FSA2269UMX technical specifications, attributes, parameters and parts with similar specifications to ONSEMI FSA2269UMX.

  • Type
  • Parameter
  • Lifecycle Status
  • ACTIVE (Last Updated: 2 days ago)
  • Factory Lead Time
  • 4 Weeks
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 10-UFQFN
  • Number of Pins
  • 10
  • Weight
  • 18.08g
  • Operating Temperature
  • -40°C~85°C TA
  • Packaging
  • Tape & Reel (TR)
  • Published
  • 2011
  • JESD-609 Code
  • e4
  • Feature
  • Break-Before-Make
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 10
  • ECCN Code
  • EAR99
  • Resistance
  • 300mOhm
  • Terminal Finish
  • Nickel/Palladium/Gold (Ni/Pd/Au)
  • Applications
  • Audio
  • Subcategory
  • Multiplexer or Switches
  • Technology
  • CMOS
  • Terminal Position
  • QUAD
  • Number of Functions
  • 2
  • Base Part Number
  • FSA2269
  • Number of Outputs
  • 4
  • Number of Channels
  • 2
  • Max Supply Voltage
  • 4.3V
  • Min Supply Voltage
  • 1.65V
  • Max Supply Current
  • 100nA
  • Turn On Delay Time
  • 110 ns
  • Supply Type
  • Single
  • Bandwidth
  • 50MHz
  • Turn-Off Delay Time
  • 65 ns
  • On-State Resistance (Max)
  • 300mOhm Typ
  • Multiplexer/Demultiplexer Circuit
  • 2:1
  • Off-state Isolation-Nom
  • 70 dB
  • On-state Resistance Match-Nom
  • 0.4Ohm
  • Switch Circuit
  • SPDT
  • Switch-off Time-Max
  • 60ns
  • Voltage - Supply, Single (V+)
  • 1.65V~4.5V
  • Drain to Source Resistance
  • 1Ohm
  • Length
  • 1.8mm
  • Height Seated (Max)
  • 0.55mm
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant
