ONSEMI FAN602FMX
Manufacturer No:
FAN602FMX
Manufacturer:
Package:
10-SOP (0.154, 3.90mm Width)
Description:
10 Terminations 5.5V~25V AC to DC power converter 75kHz~140kHz
Quantity:
Delivery:
Payment:
In Stock :Available
Price not displayed? Please send an RFQ, and we will respond immediately.
FAN602FMX information
ONSEMI FAN602FMX technical specifications, attributes, parameters and parts with similar specifications to ONSEMI FAN602FMX.
- Type
- Parameter
- Lifecycle Status
- ACTIVE (Last Updated: 2 days ago)
- Factory Lead Time
- 6 Weeks
- Mount
- Surface Mount
- Mounting Type
- Surface Mount
- Package / Case
- 10-SOP (0.154, 3.90mm Width)
- Weight
- 91mg
- Operating Temperature
- -40°C~150°C TJ
- Packaging
- Tape & Reel (TR)
- Published
- 2002
- JESD-609 Code
- e3
- Pbfree Code
- yes
- Part Status
- Active
- Moisture Sensitivity Level (MSL)
- 3 (168 Hours)
- Number of Terminations
- 10
- Terminal Finish
- Tin (Sn)
- Technology
- MOS
- Terminal Position
- DUAL
- Terminal Form
- GULL WING
- Number of Functions
- 1
- Supply Voltage
- 15V
- Terminal Pitch
- 1mm
- JESD-30 Code
- R-PDSO-G10
- Analog IC - Other Type
- SWITCHING CONTROLLER
- Voltage - Supply (Vcc/Vdd)
- 5.5V~25V
- Topology
- Flyback
- Control Mode
- CURRENT-MODE
- Frequency - Switching
- 75kHz~140kHz
- Input Voltage (Max)
- 400V
- Control Technique
- PULSE WIDTH MODULATION
- Supply Current-Max (Isup)
- 3mA
- Switcher Configuration
- BUCK-BOOST
- Internal Switch(s)
- No
- Fault Protection
- Over Temperature, Over Voltage
- Output Isolation
- Isolated
- Voltage - Start Up
- 17.2V
- Length
- 4.9mm
- Height Seated (Max)
- 1.75mm
- Width
- 3.9mm
- RoHS Status
- RoHS Compliant
Download datasheets and manufacturer documentation for ONSEMI FAN602FMX.
PCN Design/Specification:
PCN Packaging:
FAN602FMX Overview
An embedded ac to dc converter is included in 10-SOP (0.154, 3.90mm Width) package.Tape & Reel (TR) case is available for the ac dc converter.Surface Mount mounts this AC/DC converter.The ac dc converter needs to be operated at -40°C~150°C TJ °C in order to perform.The AC DC converter utilizes a type SWITCHING CONTROLLER analog IC.There is 75kHz~140kHz switching frequency.Supply voltage (Vcc/Vdd) does not need to exceed 5.5V~25V .As a result, it has a total of 10 terminations.The ac dc converters are suitable for mounting by Surface Mount .Unique techniques can be used to ensure input voltage at the maximum value of 400V .It is important to keep this AC to DC converter set to 15V .
FAN602FMX Features
Packaged with 10-SOP (0.154, 3.90mm Width)
Switching Frequency at 75kHz~140kHz
FAN602FMX Applications
There are a lot of ON Semiconductor
FAN602FMX AC DC Converters applications.
- Linear Adapter Replacements
- Chargers for cell/cordless phones
- PDAs
- MP3
- Portable audio
- Adapters
- Networking
- Battery Chargers
- Power Adaptors
- Standby Power Supplies
