FAN5608HMPX information

Rochester FAN5608HMPX technical specifications, attributes, parameters and parts with similar specifications to Rochester FAN5608HMPX.

  • Type
  • Parameter
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 12-WQFN Exposed Pad
  • Surface Mount
  • YES
  • Operating Temperature
  • -40°C~85°C TA
  • Packaging
  • Tape & Reel (TR)
  • JESD-609 Code
  • e4
  • Pbfree Code
  • yes
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 12
  • ECCN Code
  • EAR99
  • Type
  • DC DC Regulator
  • Terminal Finish
  • NICKEL PALLADIUM GOLD
  • Applications
  • Backlight
  • Additional Feature
  • CAN DRIVE UPTO 6 LED
  • Terminal Position
  • QUAD
  • Terminal Form
  • NO LEAD
  • Peak Reflow Temperature (Cel)
  • 260
  • Number of Functions
  • 1
  • Terminal Pitch
  • 0.8mm
  • Reach Compliance Code
  • unknown
  • Frequency
  • 500kHz
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Pin Count
  • 12
  • Qualification Status
  • Not Qualified
  • Voltage - Output
  • 18V
  • Topology
  • Step-Up (Boost)
  • Current - Output / Channel
  • 20mA
  • Internal Switch(s)
  • Yes
  • fmax-Min
  • 0.5 MHz
  • Dimming
  • PWM
  • Number of Segments
  • 2
  • Voltage - Supply (Max)
  • 5.5V
  • Voltage - Supply (Min)
  • 2.7V
  • Multiplexed Display Capability
  • NO
  • Length
  • 4mm
  • Height Seated (Max)
  • 0.8mm
  • Width
  • 4mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for Rochester FAN5608HMPX.

Datasheets:

FAN5608HMPX Overview


Board space is saved by its 12-WQFN Exposed Pad package.This LED driver has 2 outputs.Surface Mount is used for mounting.This emerges as a DC DC Regulator with high efficiency and reliability.The led light driver is capable of working normally at -40°C~85°C TA.There are considerable benefits for Backlight.Based on the frequency of 500kHz, it operates.It operates with 12 terminations.Undetermined failures will occur if the voltage supply is less than 2.7V.It consists of 2 segments.The output voltage is 18V.There are 12 pins on it.The supply voltage is optimized to offer a maximum value of 5.5V.Furthermore, this LED driver has a CAN DRIVE UPTO 6 LED characteristic.

FAN5608HMPX Features


Available in the 12-WQFN Exposed Pad package
Operating temperature of -40°C~85°C TA
Frequency of 500kHz
CAN DRIVE UPTO 6 LED


FAN5608HMPX Applications


There are a lot of Rochester Electronics, LLC
FAN5608HMPX LED Driver ICs applications.


  • Down lighting
  • Architectural lighting
  • Street lighting
  • Stage and Studio lighting
  • Refrigeration lighting
  • Portable lighting
  • Gallery lighting
  • Museum lighting
  • High-end retail lighting
  • Medical surgery lighting

User Guide
