Manufacturer No:

FAN5078D3MPX

Manufacturer:

ONSEMI

Package:

24-WQFN Exposed Pad

Description:

Converter, DDR Specialized Voltage Regulator -10°C~85°C FAN5078 24-WQFN Exposed Pad

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

FAN5078D3MPX information

ONSEMI FAN5078D3MPX technical specifications, attributes, parameters and parts with similar specifications to ONSEMI FAN5078D3MPX.

  • Type
  • Parameter
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 24-WQFN Exposed Pad
  • Supplier Device Package
  • 24-MLP (5x5)
  • Operating Temperature
  • -10°C~85°C
  • Packaging
  • Tape & Reel (TR)
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Applications
  • Converter, DDR
  • Base Part Number
  • FAN5078
  • Number of Outputs
  • 3
  • Voltage - Input
  • 4.5V~5.5V

Download datasheets and manufacturer documentation for ONSEMI FAN5078D3MPX.

Datasheets:

FAN5078D3MPX Description


The FAN5078D3MPX DDR memory regulator combines a high-efficiency Pulse-Width Modulated (PWM) controller for memory supply voltage generation, VDDQ, and a linear regulator for termination voltage generation (VTT).



FAN5078D3MPX Features


  • Control to generate 5V USB

  • ACPI drive and control for 5V DUAL generation

  • 3.3V internal LDO for 3V-ALW generation

  • 300kHz fixed-frequency switching

  • RDS(ON) current sensing or optional current-sense resistor for precision over-current detect

  • Internal synchronous boot diode

  • Common Power-Good signal for all voltages

  • Input under-voltage lockout (UVLO)

  • Thermal shutdown

  • Latched multi-fault protection

  • PWM regulator for V

  • Linear LDO regulator generates VTT = VDDQ/2, 1.5A peak sink/source capability

  • AMT / M-state support

  • Precision reference output for ULDO controllers

  • 24-pin 5x5mm MLP package



FAN5078D3MPX Applications


  • DDR VDDQ and VTT voltage generation with ACPI support for DDR3

  • Memory Power Solutions for Desktop PCs

  • Memory Power Solutions for Servers
