EPM9560ARC240-10 Information

INTEL EPM9560ARC240-10 technical specifications, attributes, parameters and parts with similar specifications to INTEL EPM9560ARC240-10.

Type
Parameter

Mounting Type
Surface Mount

Package / Case
240-BFQFP Exposed Pad

Surface Mount
YES

Operating Temperature
0°C~70°C TA

Packaging
Tray

Series
MAX® 9000A

JESD-609 Code
e0

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
240

Type
Parameter

ECCN Code
3A991

Terminal Finish
Tin/Lead (Sn/Pb)

HTS Code
8542.39.00.01

Subcategory
Programmable Logic Devices

Technology
CMOS

Terminal Position
QUAD

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
220

Supply Voltage
5V

Terminal Pitch
0.5mm

Download datasheets and manufacturer documentation for INTEL EPM9560ARC240-10.

EPM9560ARC240-10 Overview

Currently, there are 560 macro cells, which are low-power cell sites (towers, antennas, masts) that serve as radio coverage.There is a 240-BFQFP Exposed Pad package containing it.There are 191 I/Os on the board.Terminations of devices are set to 240.QUAD is the terminal position of this electrical part.A voltage of 5Vprovides power to the device.There is a part in the family Programmable Logic Devices.It is recommended that the chip be packaged by Tray.The device operates at a temperature of 0°C~70°C TA in order to ensure its reliability.Ideally, the chip should be mounted by Surface Mount.The MAX® 9000A series FPGA is one of these types.The EPM9560 can be used to identify its related parts.For digital circuits, there are 12000 gates. These devices serve as building blocks.In total, there are 35 logic elements/blocks.A power supply of 3.3/55V is required to operate it.In this case, the maximum supply voltage (Vsup) is 5.25V.Vsup (supply voltage) must be greater than 4.75V.Ideally, its clock frequency should not exceed 144.9MHz.

EPM9560ARC240-10 Features

240-BFQFP Exposed Pad package
191 I/Os
The operating temperature of 0°C~70°C TA
3.3/55V power supplies

EPM9560ARC240-10 Applications

There are a lot of Intel
EPM9560ARC240-10 CPLDs applications.

Bootloaders for FPGAs
Address decoders
Custom state machines
Digital systems
Portable digital devices
Handheld digital devices
Battery operated portable devices
Complex programmable logic devices
Digital designs
Field programmable gate
