EP4SGX530HH35C4ES Information

INTEL EP4SGX530HH35C4ES technical specifications, attributes, parameters and parts with similar specifications to INTEL EP4SGX530HH35C4ES.

Type
Parameter

Mount
Surface Mount

Package / Case
FCBGA

Published
2008

JESD-609 Code
e0

Pbfree Code
no

Number of Terminations
1152

ECCN Code
3A001.A.7.A

Terminal Finish
TIN LEAD

Max Operating Temperature
85°C

Min Operating Temperature
0°C

Type
Parameter

HTS Code
8542.39.00.01

Terminal Position
BOTTOM

Terminal Form
BALL

Peak Reflow Temperature (Cel)
220

Supply Voltage
0.9V

Terminal Pitch
1mm

Time@Peak Reflow Temperature-Max (s)
30

Pin Count
1152

JESD-30 Code
S-PBGA-B

Qualification Status
Not Qualified

Download datasheets and manufacturer documentation for INTEL EP4SGX530HH35C4ES.

EP4SGX530HH35C4ES Overview

A FCBGA package contains it, and it is available for download. There are FIELD PROGRAMMABLE GATE ARRAY transistors in this type of FPGA. Its 564 I/Os help it transfer data more efficiently. A fundamental building block contains 531200 logic elements or cells. Power is provided by a 0.9V-volt supply. In total, there are a total of 1152 terminations on fpga chips. A significant amount of RAM is allocated to this FPGA module to ensure that the program can operate normally. Providing the FPGA is mounted in Surface Mount as per the specifications of the IC, then it should work perfectly according to its specifications. A maximum operating temperature of 85°C can be reached by this module. Over 0°C should be the operating temperature. Featuring 1152 pins in total, it is a versatile device. The basic building block of the system is composed of 21248 logic blocks (LABs). Most commonly, this device makes use of an oscillating crystal frequency of 717MHz to operate. In order to keep this FPGA from malfunctioning, the supply voltage should be greater than 0.87V.

EP4SGX530HH35C4ES Features

564 I/Os
85°C gates
21248 logic blocks (LABs)

EP4SGX530HH35C4ES Applications

There are a lot of Altera
EP4SGX530HH35C4ES FPGAs applications.

Integrating multiple SPLDs
Voice recognition
Cryptography
Filtering and communication encoding
Aerospace and Defense
Medical Electronics
Audio
Automotive
Consumer Electronics
Distributed Monetary Systems
