Renesas EL7641AILTZ

Manufacturer No:

EL7641AILTZ

Manufacturer:

Renesas

Package:

QFN

Description:

20V 260 Cel QUAD Specialized Voltage Regulator 32 Pins 32 Terminations QFN

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

EL7641AILTZ information

Renesas EL7641AILTZ technical specifications, attributes, parameters and parts with similar specifications to Renesas EL7641AILTZ.

Type
Parameter

Mount
Surface Mount

Package / Case
QFN

Number of Pins
32

Published
2005

JESD-609 Code
e3

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
32

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Subcategory
Power Management Circuits

Terminal Position
QUAD

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Time@Peak Reflow Temperature-Max (s)
40

Pin Count
32

Number of Outputs
5

Operating Supply Voltage
5.5V

Input Voltage-Nom
3V

Temperature Grade
INDUSTRIAL

Analog IC - Other Type
SWITCHING REGULATOR

Voltage - Output
20V

Control Mode
CURRENT-MODE

Frequency - Switching
1.35MHz

Max Input Voltage
5.5V

Control Technique
PULSE WIDTH MODULATION

Supply Current-Max (Isup)
10mA

Switcher Configuration
BOOST

Height Seated (Max)
0.8mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Renesas EL7641AILTZ.

Datasheets:

intersil-el7641ailtz-datasheets-3870.pdf

EL7641AILTZ Overview

There are 5 outputs supported by the voltage regulator. Transport is made easy with the package of QFN. Volatge output for this voltage controller is 20V. It contains terminals with the number 32. The part has received praise for being a SWITCHING REGULATOR voltage regulator. Initially, the pinout of the alternator regulator begins with 32 pins. Surface Mount is there for mounting on a PCB or another board. There are 32 pins on the power supply regulator. The AC voltage regulator and other Power Management Circuits play an important role in the industry. It cannot be operated at temperatures below -40°C. In general, temperatures higher than 85°Care not recommended. It is necessary to have an operating supply voltage of 5.5V for normal operation. A voltage higher than 2.6Vis required for the input of this alternator regulator. In this voltage regulator, the switching frequency is set to 1.35MHz.

EL7641AILTZ Features

SWITCHING REGULATOR analog IC
Supply voltage: 5.5V
Switching at 1.35MHz

EL7641AILTZ Applications

There are a lot of Intersil (Renesas Electronics America)
EL7641AILTZ Specialized Voltage Regulators applications.

DDR Vooo and V? Voltage Generation
PC Dual Power Supply
Server DDR Power
Desktop Computer
Graphics Cards
Cell Phones
Wireless Modems
PCS Phones
Two-Way Pagers
PHS Phones
