Advanced Linear Devices Inc. EH4295

Manufacturer No:

EH4295

Manufacturer:

Advanced Linear Devices Inc.

Package:

Module

Description:

70mV~3V Specialized Power Management ICs 260?A

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

EH4295 information

Advanced Linear Devices Inc. EH4295 technical specifications, attributes, parameters and parts with similar specifications to Advanced Linear Devices Inc. EH4295.

Type
Parameter

Factory Lead Time
8 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
Module

Supplier Device Package
Module

Operating Temperature
0°C~70°C

Packaging
Bulk

Published
2011

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Resistance
950Ohm

Max Operating Temperature
70°C

Min Operating Temperature
0°C

Applications
Energy Harvesting

Voltage - Supply
70mV~3V

Output Voltage
12V

Operating Supply Current
260?A

Current - Supply
260?A

Max Input Voltage
4V

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Advanced Linear Devices Inc. EH4295.

Datasheets:

advancedlineardevicesinc-ehj5c-datasheets-5681.pdf

EH4295 Overview

It is acceptable to ship in the direction of Bulk .In order to facilitate transportation, it is packaged the power management in Module .For ease of adaptability, Surface Mount is an universal mounting method.Applications targeting this power management include Energy Harvesting and others.Ideally, the operating temperature of the power management ic should be set at 0°C~70°C in order to prevent malfunction.The power management runs on 70mV~3V voltage.It is equipped with a Surface Mount for mounting on a PCB or other board.There is 260?A voltage applied to this power management ic.Current should be conducted at 260?A when the power ic is supplied with power.There is a voltage output of 12V .A temperature higher than 70°C should not be used.A temperature lower than 0°C is unsuitable for the ic power supply.

EH4295 Features

Mainly used in Energy Harvesting applications
Operating temperature: 0°C~70°C

EH4295 Applications

There are a lot of Advanced Linear Devices Inc.
EH4295Power Management applications.

Portable Navigation Devices
Portable Media Players
Portable Systems
Hand-Held Systems
Space satellite point of load supply
Communications payload
Optical imaging payload
Desktop PC
Motherboard
Standard notebook PC
