ED951/9 information

On-Shore ED951/9 technical specifications, attributes, parameters and parts with similar specifications to On-Shore ED951/9.

  • Type
  • Parameter
  • Factory Lead Time
  • 8 Weeks
  • Contact Material
  • Copper
  • Contact Plating
  • Tin
  • Mount
  • Free Hanging
  • Mounting Type
  • Free Hanging (In-Line)
  • Number of Pins
  • 9
  • Housing Material
  • Polyamide (PA), Nylon
  • Operating Temperature
  • -30°C~105°C
  • Packaging
  • Bulk
  • Series
  • ED951
  • Feature
  • Mating Flange, Retention Latches (Non-Wire Side)
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Screw
  • Type
  • Plug, Female Sockets
  • Number of Positions
  • 9
  • Max Operating Temperature
  • 105°C
  • Min Operating Temperature
  • -30°C
  • Color
  • Green
  • Number of Rows
  • 1
  • Pitch
  • 0.197 5.00mm
  • Insulation Height
  • 0.591 15.00mm
  • Termination Style
  • Screw
  • Lead Pitch
  • 5mm
  • Voltage
  • 300V
  • Number of Levels
  • 1
  • Current
  • 15A
  • Wire Gauge (Max)
  • 22 AWG
  • Wire Gauge (Min)
  • 12 AWG
  • Voltage - UL
  • 300V
  • Wire Gauge or Range - AWG
  • 12-22 AWG
  • Current - UL
  • 15A
  • Torque - Screw
  • 0.5 Nm (4.4 Lb-In)
  • Positions Per Level
  • 9
  • Plug Wire Entry
  • 180°
  • Wire Gauge or Range - mm²
  • 2.5mm2
  • Wire Strip Length
  • 6mm
  • Number of Positions Per Level
  • 9
  • Screw Size
  • M3
  • Height
  • 15mm
  • Length
  • 55mm
  • Width
  • 17.3mm
  • Material Flammability Rating
  • UL94 V-0
  • RoHS Status
  • RoHS Compliant
  • Flammability Rating
  • UL94 V-0
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for On-Shore ED951/9.

Datasheets:

ED951/9 Overview
