Manufacturer No:

ED650/5DS

Manufacturer:

On-Shore

Package:

Description:

0.276 7.00mm Gray Bulk Polyamide (PA), Nylon Through Hole Vertical with Board Screw 1 Levels 16-28 AWG ED650/DS

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ED650/5DS information

On-Shore ED650/5DS technical specifications, attributes, parameters and parts with similar specifications to On-Shore ED650/5DS.

  • Type
  • Parameter
  • Factory Lead Time
  • 8 Weeks
  • Contact Plating
  • Brass
  • Mount
  • Through Hole
  • Mounting Type
  • Through Hole
  • Number of Pins
  • 5
  • Housing Material
  • Polyamide (PA), Nylon
  • Contact Material - Plating
  • Brass
  • Clamp Material - Plating
  • Copper Tin Alloy
  • Operating Temperature
  • -30°C~105°C
  • Packaging
  • Bulk
  • Series
  • ED650/DS
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Screw
  • Number of Positions
  • 5
  • Max Operating Temperature
  • 105°C
  • Min Operating Temperature
  • -30°C
  • Color
  • Gray
  • Number of Rows
  • 1
  • Pitch
  • 0.276 7.00mm
  • Lead Pitch
  • 7mm
  • Housing Color
  • Grey
  • Wire Gauge
  • 16-28 AWG
  • Voltage
  • 250V
  • Number of Levels
  • 1
  • Current
  • 6A
  • Wire Gauge (Max)
  • 28 AWG
  • Wire Gauge (Min)
  • 16 AWG
  • Torque - Screw
  • 0.4 Nm (3.5 Lb-In)
  • Positions Per Level
  • 5
  • Mating Orientation
  • Vertical with Board
  • Wire Termination
  • Screw
  • Screw Thread
  • M2
  • Number of Positions Per Level
  • 5
  • Height
  • 6.5mm
  • Length
  • 31.5mm
  • Width
  • 8.2mm
  • RoHS Status
  • RoHS Compliant
  • Flammability Rating
  • UL94 V-0

Download datasheets and manufacturer documentation for On-Shore ED650/5DS.

Datasheets:

ED650/5DS Overview


Through Hole indicates that the device is mounted.An Bulk case is utilized for packaging the product.The product is a part of the ED650/DS Series.It is equipped with 5 pins.Use it below 105°C.A minimum temperature of -30°C must be maintained for the operation of this device.By Through Hole, the part is mounted.Operating temperature is set to -30°C~105°C.
