On-Shore ED555/9DS

Manufacturer No:

ED555/9DS

Manufacturer:

Package:

Description:

0.138 3.50mm Gray Bulk Polyamide (PA), Nylon Through Hole Horizontal with Board Screw - Leaf Spring, Wire Guard 1 Levels 16-28 AWG ED555/DS

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ED555/9DS information

On-Shore ED555/9DS technical specifications, attributes, parameters and parts with similar specifications to On-Shore ED555/9DS.

Type
Parameter

Factory Lead Time
8 Weeks

Contact Material
Brass

Contact Plating
Brass

Mount
Through Hole

Mounting Type
Through Hole

Number of Pins
9

Housing Material
Polyamide (PA), Nylon

Contact Material - Plating
Brass

Clamp Material - Plating
Steel, Stainless

Operating Temperature
-30°C~105°C

Packaging
Bulk

Series
ED555/DS

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Termination
Screw

Number of Positions
9

Max Operating Temperature
105°C

Min Operating Temperature
-30°C

Color
Gray

Number of Rows
1

Pitch
0.138 3.50mm

Lead Pitch
3.5mm

Housing Color
Grey

Wire Gauge
16-28 AWG

Plating
Steel

Number of Levels
1

Current
6A

Wire Gauge (Max)
28 AWG

Wire Gauge (Min)
16 AWG

Torque - Screw
0.4 Nm (3.5 Lb-In)

Positions Per Level
9

Mating Orientation
Horizontal with Board

Wire Termination
Screw - Leaf Spring, Wire Guard

Screw Thread
M2

Number of Positions Per Level
9

Height
8.2mm

Length
31.5mm

Width
6.2mm

RoHS Status
RoHS Compliant

Flammability Rating
UL94 V-0

Lead Free
Lead Free

Download datasheets and manufacturer documentation for On-Shore ED555/9DS.

Datasheets:

onshoretechnology-ed5559ds-datasheets-4565.pdf

ED555/9DS Overview

There is a Through Hole mounting type for the device.This product is packaged in a case marked Bulk.Product number ED555/DS belongs to the ED555/DS Series.A 9 pin is provided on the device.Whenever the temperature is below 105°C, it's best.There is a minimum temperature requirement of [0°C] for this device.There is a Through Hole mount on the part.This device operates at a temperature of -30°C~105°C.

ED555/9DS Features

ED555/DS series

ED555/9DS Applications

There are a lot of On Shore Technology Inc.
ED555/9DS Terminal Blocks applications.

Medical technology
Military Technology
Measuring & Control Technology
Instrumentation
Automotive Electronics
Telecommunications
Data Technology
Blowers
Control panels
Electrical substations
