On-Shore ED3001/9-KD
On-Shore ED3001/9-KD

On-Shore ED3001/9-KD

Manufacturer No:

ED3001/9-KD

Manufacturer:

On-Shore

Package:

Description:

0.197 5.00mm Gray, Slate Bulk Polyamide (PA), Nylon Through Hole 45° (135°) Angle with Board Screwless - Leg Spring, Push-In Spring 1 Levels 14-28 AWG ED3001/KD

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ED3001/9-KD information

On-Shore ED3001/9-KD technical specifications, attributes, parameters and parts with similar specifications to On-Shore ED3001/9-KD.

  • Type
  • Parameter
  • Factory Lead Time
  • 8 Weeks
  • Contact Plating
  • Copper
  • Mount
  • Through Hole
  • Mounting Type
  • Through Hole
  • Number of Pins
  • 9
  • Housing Material
  • Polyamide (PA), Nylon
  • Contact Material - Plating
  • Copper
  • Operating Temperature
  • -30°C~105°C
  • Packaging
  • Bulk
  • Series
  • ED3001/KD
  • Feature
  • Interlocking (Side), Lever Actuated
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Screwless
  • Number of Positions
  • 9
  • Max Operating Temperature
  • 105°C
  • Min Operating Temperature
  • -30°C
  • Color
  • Gray, Slate
  • Number of Rows
  • 1
  • Pitch
  • 0.197 5.00mm
  • Lead Pitch
  • 5mm
  • Housing Color
  • Grey
  • Wire Gauge
  • 14-28 AWG
  • Voltage
  • 300V
  • Current
  • 16A
  • Wire Gauge (Max)
  • 28 AWG
  • Wire Gauge (Min)
  • 14 AWG
  • Positions Per Level
  • 9
  • Mating Orientation
  • 45° (135°) Angle with Board
  • Wire Termination
  • Screwless - Leg Spring, Push-In Spring
  • Number of Positions Per Level
  • 9
  • Height
  • 12.9mm
  • Length
  • 45mm
  • Width
  • 14.2mm
  • RoHS Status
  • RoHS Compliant
  • Flammability Rating
  • UL94 V-0

Download datasheets and manufacturer documentation for On-Shore ED3001/9-KD.

Datasheets:

ED3001/9-KD Overview


There is a mounting type of Through Hole for this device.It is necessary to use a Bulk case for packaging the product.This product is part of the ED3001/KD Series.Devices with 9 pins are available.You should use it when it's below 105°C.A minimum temperature of -30°C is required for the operation of this device.In many ways, its Interlocking (Side), Lever Actuated feature makes it more powerful.Through Hole is used to mount the part.In this case, the device operates at -30°C~105°C Operating Temperature.

ED3001/9-KD Features


ED3001/KD series


ED3001/9-KD Applications


There are a lot of On Shore Technology Inc.
ED3001/9-KD Terminal Blocks applications.


  • Transportation
  • Embedded systems
  • Datacom
  • Communication
  • Medical technology
  • Military Technology
  • Measuring & Control Technology
  • Instrumentation
  • Automotive Electronics
  • Telecommunications

User Guide
