On-Shore ED1100/6
On-Shore ED1100/6

On-Shore ED1100/6

Manufacturer No:

ED1100/6

Manufacturer:

On-Shore

Package:

Description:

Bulk 0.197 5.00mm Green 1 Levels Free Hanging (In-Line) Plug, Female Sockets ED1100 Polyamide (PA), Nylon Copper Tin Alloy

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ED1100/6 information

On-Shore ED1100/6 technical specifications, attributes, parameters and parts with similar specifications to On-Shore ED1100/6.

  • Type
  • Parameter
  • Factory Lead Time
  • 8 Weeks
  • Contact Material
  • Copper Tin Alloy
  • Contact Plating
  • Tin
  • Mount
  • Free Hanging
  • Mounting Type
  • Free Hanging (In-Line)
  • Number of Pins
  • 6
  • Housing Material
  • Polyamide (PA), Nylon
  • Operating Temperature
  • -30°C~105°C
  • Packaging
  • Bulk
  • Series
  • ED1100
  • Feature
  • Retention Latches (Wire Side)
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Screw
  • Type
  • Plug, Female Sockets
  • Number of Positions
  • 6
  • Max Operating Temperature
  • 105°C
  • Min Operating Temperature
  • -30°C
  • Color
  • Green
  • Number of Rows
  • 1
  • Pitch
  • 0.197 5.00mm
  • Insulation Height
  • 1.043 26.50mm
  • Termination Style
  • Screw
  • Lead Pitch
  • 5mm
  • Voltage
  • 300V
  • Number of Levels
  • 1
  • Current
  • 15A
  • Wire Gauge (Max)
  • 22 AWG
  • Wire Gauge (Min)
  • 10 AWG
  • Voltage - UL
  • 300V
  • Wire Gauge or Range - AWG
  • 10-22 AWG
  • Current - UL
  • 15A
  • Torque - Screw
  • 0.5 Nm (4.4 Lb-In)
  • Positions Per Level
  • 6
  • Plug Wire Entry
  • 90°
  • Wire Gauge or Range - mm²
  • 2.5mm2
  • Wire Strip Length
  • 7mm
  • Number of Positions Per Level
  • 6
  • Screw Size
  • M3
  • Height
  • 26.5mm
  • Length
  • 30mm
  • Width
  • 12.5mm
  • Material Flammability Rating
  • UL94 V-0
  • RoHS Status
  • RoHS Compliant
  • Flammability Rating
  • UL94 V-0
  • Lead Free
  • Contains Lead

Download datasheets and manufacturer documentation for On-Shore ED1100/6.

Datasheets:

ED1100/6 Overview


Its mounting type is Free Hanging (In-Line).Packaging is performed using a Bulk case.It is part of the ED1100 Series of products.6 pins are provided on the device.Whenever it's below 105°C, it's best to use it.The device must operate at a temperature of -30°C at all times.A number of features make it more powerful because of its Retention Latches (Wire Side) feature.Free Hanging mounts the part.There is no operating temperature for the device.Several of the benefits of this part are also shared by other Plug, Female Sockets products.
