On-Shore ED104/6DS

Manufacturer No:

ED104/6DS

Manufacturer:

Package:

Description:

0.197 5.00mm Gray Bulk Polyamide (PA), Nylon Through Hole Horizontal with Board Screw - Leaf Spring, Wire Guard 1 Levels 14-22 AWG ED104/DS

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ED104/6DS information

On-Shore ED104/6DS technical specifications, attributes, parameters and parts with similar specifications to On-Shore ED104/6DS.

Type
Parameter

Factory Lead Time
8 Weeks

Mount
Through Hole

Mounting Type
Through Hole

Housing Material
Polyamide (PA), Nylon

Contact Material - Plating
Brass

Clamp Material - Plating
Steel, Stainless

Operating Temperature
-30°C~105°C

Packaging
Bulk

Series
ED104/DS

Pbfree Code
no

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Termination
Screw

Color
Gray

Pitch
0.197 5.00mm

Lead Pitch
5mm

Housing Color
Grey

Wire Gauge
14-22 AWG

Voltage
300V

Plating
Steel

Number of Levels
1

Current
15A

Wire Gauge (Max)
22 AWG

Wire Gauge (Min)
14 AWG

Torque - Screw
0.8 Nm (7.1 Lb-In)

Mating Orientation
Horizontal with Board

Wire Termination
Screw - Leaf Spring, Wire Guard

Screw Thread
M3

Number of Positions Per Level
6

Height
12.5mm

Length
30mm

Width
9mm

RoHS Status
RoHS Compliant

Flammability Rating
UL94 V-0

Download datasheets and manufacturer documentation for On-Shore ED104/6DS.

Datasheets:

onshoretechnologyinc-ed1046ds-datasheets-1236.pdf

onshoretechnology-ed1046ds-datasheets-1494.pdf

ED104/6DS Overview

Its mounting type is Through Hole.Packaging is performed using a Bulk case.It is part of the ED104/DS Series of products.Through Hole mounts the part.There is no operating temperature for the device.
