Manufacturer No:

DSA300I45NA

Manufacturer:

LITTELFUSE

Package:

SOT-227-4, miniBLOC

Description:

Schottky Diode Rectifier Fast Recovery =< 500ns, > 200mA (Io) 840mV @ 300A 3mA @ 45V 4-Termination Tube SOT-227-4, miniBLOC Chassis Mount

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

DSA300I45NA information

LITTELFUSE DSA300I45NA technical specifications, attributes, parameters and parts with similar specifications to LITTELFUSE DSA300I45NA.

  • Type
  • Parameter
  • Factory Lead Time
  • 39 Weeks
  • Mount
  • Chassis Mount, Screw
  • Mounting Type
  • Chassis Mount
  • Package / Case
  • SOT-227-4, miniBLOC
  • Number of Pins
  • 4
  • Diode Element Material
  • SILICON
  • Packaging
  • Tube
  • Published
  • 2013
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 4
  • ECCN Code
  • EAR99
  • Max Operating Temperature
  • 150°C
  • Min Operating Temperature
  • -40°C
  • Additional Feature
  • FREE WHEELING DIODE, HIGH RELIABILITY LOW NOISE, UL RECOGNIZED
  • Subcategory
  • Rectifier Diodes
  • Terminal Position
  • UPPER
  • Terminal Form
  • UNSPECIFIED
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Reach Compliance Code
  • unknown
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Pin Count
  • 2
  • Qualification Status
  • Not Qualified
  • Number of Elements
  • 1
  • Speed
  • Fast Recovery =< 500ns, > 200mA (Io)
  • Diode Type
  • Schottky
  • Current - Reverse Leakage @ Vr
  • 3mA @ 45V
  • Voltage - Forward (Vf) (Max) @ If
  • 840mV @ 300A
  • Case Connection
  • ISOLATED
  • Application
  • SOFT RECOVERY
  • Max Reverse Voltage (DC)
  • 45V
  • Average Rectified Current
  • 300A
  • Number of Phases
  • 1
  • Capacitance @ Vr, F
  • 16500pF @ 5V 1MHz
  • Peak Non-Repetitive Surge Current
  • 5.3kA
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for LITTELFUSE DSA300I45NA.

Datasheets:

DSA300I45NA Overview


Devices with this rating have an average rectified current of 300A volts.

DSA300I45NA Features


an average rectified current of 300A volts


DSA300I45NA Applications


There are a lot of IXYS
DSA300I45NA applications of single-phase diode rectifier.


  • DC motor control and drives
  • Battery chargers
  • Welders
  • Power converters
  • Reverse Polarity Protection
  • Ultra High-Speed Switching
  • Freewheeling
  • Polarity Protection Diode
  • Recirculating Diode
  • Switching Diode

User Guide
