Diodes DMP3028LFDE-13
Diodes DMP3028LFDE-13

Diodes DMP3028LFDE-13

Manufacturer No:

DMP3028LFDE-13

Manufacturer:

Diodes

Package:

6-UDFN Exposed Pad

Description:

MOSFET (Metal Oxide) P-Channel Tape & Reel (TR) 32m ? @ 7A, 10V ±20V 1241pF @ 15V 22nC @ 10V 30V 6-UDFN Exposed Pad

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

DMP3028LFDE-13 information

Diodes DMP3028LFDE-13 technical specifications, attributes, parameters and parts with similar specifications to Diodes DMP3028LFDE-13.

  • Type
  • Parameter
  • Factory Lead Time
  • 22 Weeks
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 6-UDFN Exposed Pad
  • Number of Pins
  • 6
  • Operating Temperature
  • -55°C~150°C TJ
  • Packaging
  • Tape & Reel (TR)
  • Published
  • 2013
  • JESD-609 Code
  • e3
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Matte Tin (Sn)
  • Subcategory
  • Other Transistors
  • Technology
  • MOSFET (Metal Oxide)
  • Peak Reflow Temperature (Cel)
  • 260
  • Time@Peak Reflow Temperature-Max (s)
  • 40
  • Configuration
  • Single
  • Number of Channels
  • 1
  • Power Dissipation-Max
  • 660mW Ta
  • Turn On Delay Time
  • 9.7 ns
  • FET Type
  • P-Channel
  • Rds On (Max) @ Id, Vgs
  • 32m ? @ 7A, 10V
  • Input Capacitance (Ciss) (Max) @ Vds
  • 1241pF @ 15V
  • Current - Continuous Drain (Id) @ 25°C
  • 6.8A Ta
  • Gate Charge (Qg) (Max) @ Vgs
  • 22nC @ 10V
  • Rise Time
  • 17.1ns
  • Drain to Source Voltage (Vdss)
  • 30V
  • Drive Voltage (Max Rds On,Min Rds On)
  • 4.5V 10V
  • Vgs (Max)
  • ±20V
  • Fall Time (Typ)
  • 40.4 ns
  • Turn-Off Delay Time
  • 60.5 ns
  • Continuous Drain Current (ID)
  • 6.8A
  • Gate to Source Voltage (Vgs)
  • 20V
  • Drain to Source Breakdown Voltage
  • -30V
  • REACH SVHC
  • No SVHC
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for Diodes DMP3028LFDE-13.

Datasheets:

Environmental Information:

PCN Assembly/Origin:

DMP3028LFDE-13 Overview


The maximum input capacitance of this device is 1241pF @ 15V, because the input capacitance of an op amp is defined as the difference between the input terminals with one input grounded.Continuous drain current (ID) is the maximum continuous current (ID) the device can conduct, and it is 6.8A.When VGS=-30V, and ID flows to VDS at -30VVDS, the drain-source breakdown voltage is -30V in this device.Before drain current conduction can begin, the device's turn-off delay time must be charged up to full capacitance. This value is 60.5 ns.During device turn-on, the input capacitance must be charged for a period of time before drain current conduction can begin, so its delay time is 9.7 ns seconds.Single MOSFETs transistor is the voltage across the gate-source terminal of a transistor that determines the gate-source voltage, VGS.The drain-to-source voltage (Vdss) of this transistor needs to be at 30V in order to operate.Using drive voltage (4.5V 10V), this device helps reduce its power consumption.

DMP3028LFDE-13 Features


a continuous drain current (ID) of 6.8A
a drain-to-source breakdown voltage of -30V voltage
the turn-off delay time is 60.5 ns
a 30V drain to source voltage (Vdss)


DMP3028LFDE-13 Applications


There are a lot of Diodes Incorporated
DMP3028LFDE-13 applications of single MOSFETs transistors.


  • Micro Solar Inverter
  • DC/DC converters
  • Power Tools
  • Motor Drives and Uninterruptible Power Supples
  • Synchronous Rectification
  • Battery Protection Circuit
  • Telecom 1 Sever Power Supplies
  • Industrial Power Supplies
  • PFC stages, hard switching PWM stages and resonant switching
  • PWM stages for e.g. PC Silverbox, Adapter, LCD & PDP TV,
