C-Ton Industries DK733
Manufacturer No:
DK733
Manufacturer:
Package:
Description:
VOLTMETER 2VDC LCD PANEL MOUNT
Quantity:
User Guide
Aichiplink operates certified in-house inspection and testing facilities to ensure all electronic components meet internationally recognized quality and compliance standards. Our quality management system is verified through ISO 9001 certification and industry-standard inspection procedures.
Please verify all part numbers, quantities, and packaging preferences before placing your order. If substitutions are acceptable, please indicate this clearly. For time-sensitive projects, confirm estimated delivery dates and stock availability in advance. Once submitted, changes or cancellations may not be possible, especially for items marked as non-cancellable/non-returnable (NCNR). For international shipments, please ensure all import documentation is complete and accurate to avoid delays.
MEANS OF PAYMENTFor your convenience, we accept multiple payment methods in USD, including PayPal, Credit Card, and Wire Transfer. Net terms may be available for qualified customers upon approval.
RFQ (REQUEST FOR QUOTATIONS)Please ensure the part numbers and quantities are accurate and complete when submitting your RFQ.
Provide target prices and acceptable alternatives, if any, to speed up the quotation process.
Quotations are subject to stock availability and may vary with market conditions. Prices and lead times are not guaranteed until a purchase order is confirmed. Ensure your contact details are correct to avoid delays in response.
Step1：Prepare product
Step2：Desiccant Protection
Step3：Vacuum Packaging
Step4：Individual Package
Step5：Anti-collision Filling
Step6：Packaging Box
1. Shipping starts at $40, but some countries will exceed $40. For example (South Africa, Brazil, India, Pakistan, Israel, etc.).
2. Some specific products need to reach the minimum order quantity.
3. It may cost additional remote fees for delivery if you are in a remote area.
Currently, our products are shipped through DHL, FedEx, SF, and UPS.
DELIVERY TIME1. Once the goods are shipped, estimated delivery time depends on the shipping methods you chose: FedEx International, 5-7 business days.
2. For in-stock parts, orders normally could be shipped out within 1-2days.
DK733 Information
C-Ton Industries DK733 technical specifications, attributes, parameters and parts with similar specifications to C-Ton Industries DK733.
- Type
- Parameter
- Factory Lead Time
- 2 Weeks
- Mount
- Panel
- Mounting Type
- Panel Mount - Window
- Operating Temperature
- 0°C~60°C
- Series
- DK720-730
- Published
- 2002
- Feature
- Bezel Sold Separately
- Part Status
- Obsolete
- Moisture Sensitivity Level (MSL)
- Not Applicable
- Termination
- PC Pins
- Type
- Parameter
- Temperature Coefficient
- 100 ppm/°C
- Type
- Voltage (Voltmeter)
- Voltage - Supply
- 5VDC
- Termination Style
- PC Pin
- Panel Cutout Dimensions
- Rectangular - 38.90mm x 21.10mm
- Accuracy
- 0.1 %
- Display Type
- LCD - Green Characters, Backlight
- Number of Characters Per Row
- 3.5
- Measuring Range
- 2VDC
- Height
- 18.3mm
Download datasheets and manufacturer documentation for C-Ton Industries DK733.
DK733 Datasheet:
The C-TON Industries DK733 is a digital panel voltmeter designed for measuring DC voltages up to 2V. It features a 3.5-digit LCD with green characters and backlighting, making it suitable for clear voltage readings in various lighting conditions. The device operates with a 5V DC supply and is intended for panel mount installations, requiring a rectangular cutout of 38.90mm x 21.10mm. Notably, the bezel for this voltmeter is sold separately. However, it's important to note that the DK733 has been marked as obsolete by the manufacturer.
Below are its key specifications:
Display:
• Digits: 3.5-digit (±1999 counts)
• Type: 7-segment backlit LCD with green characters
• Polarity: Automatic, with "-" sign displayed for negative voltages
• Decimal Points: User-selectable, three positions
Inputs:
• Measurement Range: 0 to 2V DC
• Input Impedance: 1 MΩ
Performance:
• Accuracy: ±0.1% of full scale plus 1 count
• Conversion Rate: Approximately 2.5 readings per second
• Normal Mode Rejection: Greater than 30 dB at 60 Hz
• Common Mode Range: ±1V DC maximum
• Common Mode Rejection: Greater than 86 dB
Power Supply:
• Voltage: 5V DC
Mounting and Dimensions:
• Mounting Type: Panel mount with window
• Panel Cutout Size: Rectangular, 38.90 mm x 21.10 mm
• Bezel: Sold separately
Operating Conditions:
• Temperature Range: 0°C to 60°C
