ADI DG508ABK

Manufacturer No:

DG508ABK

Manufacturer:

ADI

Package:

CDIP

Description:

16 Terminations 16 Pin Signal switch 1 Functions

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

DG508ABK information

ADI DG508ABK technical specifications, attributes, parameters and parts with similar specifications to ADI DG508ABK.

Type
Parameter

Package / Case
CDIP

Surface Mount
NO

Number of Pins
16

Packaging
Tube

Published
2010

JESD-609 Code
e0

Pbfree Code
no

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
16

ECCN Code
EAR99

Terminal Finish
Tin/Lead (Sn/Pb)

HTS Code
8542.39.00.01

Subcategory
Multiplexer or Switches

Technology
CMOS

Terminal Position
DUAL

Terminal Form
THROUGH-HOLE

Peak Reflow Temperature (Cel)
240

Number of Functions
1

Supply Voltage
15V

Terminal Pitch
2.54mm

Time@Peak Reflow Temperature-Max (s)
20

Pin Count
16

Operating Temperature (Max)
85°C

Power Supplies
+-15V

Temperature Grade
OTHER

Number of Channels
8

Analog IC - Other Type
SINGLE-ENDED MULTIPLEXER

Neg Supply Voltage-Nom (Vsup)
-15V

Max Dual Supply Voltage
18V

On-State Resistance (Max)
450Ohm

Min Dual Supply Voltage
4.5V

Off-state Isolation-Nom
68 dB

On-state Resistance Match-Nom
27Ohm

Switching
BREAK-BEFORE-MAKE

Switch-on Time-Max
1500ns

Switch-off Time-Max
1000ns

Height Seated (Max)
5.08mm

Width
7.62mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for ADI DG508ABK.

ConflictMineralStatement:

maximintegrated-ds1075z66n-conflictmineralstatement-7504.pdf

DG508ABK Overview

Due to the lack of space on the board, digital switch is provided in the CDIP.It is packaged according to the Tube method.There are 16 terminations included in its basic configuration.In this case, 15V is the voltage supplied to the multiplexer's system.Signal switch has 16 component pins.THROUGH-HOLE represents the end of conductors.This multiplexer ic has 16 pins configured.In order to maintain mux switch's normal operation, power is provided to +-15V.The digital switch ic is a part of an electronic system classified as Multiplexer or Switches.This turn signal switch's circuit is based on a circuit with 8 channels.It reaches a maximum operating temperature of the switches of 85°C.This digital switch uses SINGLE-ENDED MULTIPLEXER as its analog integrated circuit.

DG508ABK Features

Supplied in the CDIP package
Power supplies of +-15V
SINGLE-ENDED MULTIPLEXER as the analog IC

DG508ABK Applications

There are a lot of Maxim Integrated
DG508ABK Signal Switches / Multiplexers / Decoders applications.

Implementing boolean functions with multiple variables
Data collection system
Audio transmission
Video transmission
Image transmission
Recording transmission
Combinational circuit
Logic gates for other digital devices
Signal router
Data communication
