VISHAY DG303BDJ

Manufacturer No:

DG303BDJ

Manufacturer:

VISHAY

Package:

14-DIP (0.300, 7.62mm)

Description:

300ns, 250ns DPST - NO/NC 50Ohm Analog Switches BREAK-BEFORE-MAKE 14 Pins 1nA 15V 14-DIP (0.300, 7.62mm)

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

DG303BDJ information

VISHAY DG303BDJ technical specifications, attributes, parameters and parts with similar specifications to VISHAY DG303BDJ.

Type
Parameter

Factory Lead Time
8 Weeks

Mount
Through Hole

Mounting Type
Through Hole

Package / Case
14-DIP (0.300, 7.62mm)

Number of Pins
14

Weight
1.620005g

Operating Temperature
-40°C~85°C TA

Packaging
Tube

Published
2009

Pbfree Code
no

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
14

Resistance
50Ohm

Subcategory
Multiplexer or Switches

Max Power Dissipation
470mW

Technology
CMOS

Number of Functions
4

Supply Voltage
15V

Pin Count
14

Operating Supply Voltage
15V

Polarity
Non-Inverting

Number of Circuits
2

Max Supply Voltage
36V

Analog IC - Other Type
SPST

Operating Supply Current
230μA

Power Dissipation
470mW

Max Supply Current
1mA

Turn On Delay Time
150 ns

Number of Inputs
4

Supply Type
Dual, Single

Neg Supply Voltage-Nom (Vsup)
-15V

Turn-Off Delay Time
130 ns

Max Dual Supply Voltage
22V

On-State Resistance (Max)
50Ohm

Min Dual Supply Voltage
7V

High Level Output Current
100mA

Dual Supply Voltage
15V

Multiplexer/Demultiplexer Circuit
2:1

Current - Leakage (IS(off)) (Max)
1nA

Channel Capacitance (CS(off), CD(off))
14pF 14pF

Switch Circuit
DPST - NO/NC

Switch Time (Ton, Toff) (Max)
300ns, 250ns

Charge Injection
8pC

Crosstalk
-74dB @ 500kHz

Switching
BREAK-BEFORE-MAKE

Drain to Source Resistance
50Ohm

Download datasheets and manufacturer documentation for VISHAY DG303BDJ.

Datasheets:

vishaysiliconix-dg303bdye3-datasheets-5523.pdf

RohsStatement:

vishaydale-imc0402rk47nj-rohsstatement-4552.pdf

DG303BDJ Overview

This electronic part is conveniently packaged in 14-DIP (0.300, 7.62mm), making it easy to ship abroad. This high-reliability packaging method uses advanced packaging methods Tube. A switch device like this is mounted in Through Hole. 2:1 is the ratio of multiplexer to demultiplexer circuits. An extended operating temperature of -40°C~85°C TA degrees Celsius. In total, there have been 14 terminations. A 15V voltage supply should turn on and run the electronic component. An injection of 14 pins is performed into the body of the electrical component. Unlike digital switches, these are based on DPST - NO/NC switching circuits. 2 circuits are used in this analogue multiplexer. Analog switches have 50Ohm internal resistance. To find out what the 14 pins do, please refer to the datasheets. It is a typical Multiplexer or Switches analog multiplexer. Users should never supply a voltage higher than 36V to a switch device. Analog switch ics with Dual, Single supply type are cost-effective. There should be 13V voltage fed to the electrical part below 13V. It would be sufficient to run this analogue multiplexer with 230μA current. The switch multiplexer may be damaged if it is exposed to voltage greater than 1mA. For this switch device, it is feasible to have two supplies. However, the voltage should not exceed 22V. The voltage should be at least 7V if you are using dual power supplies. This product is integrated with an analog integrated circuit (IC) of type SPST. Operating voltages of 15V are compatible with the electrical part. In order to operate the 4 inputs, there are several steps to follow. Resistivity from Drain to Source is 50Ohm for this electronic part.

DG303BDJ Features

Switch Circuit: DPST - NO/NC
230μA Supply Current
Drain-to-Source resistance: 50Ohm

DG303BDJ Applications

There are a lot of Vishay Siliconix
DG303BDJ Analog Switches & Multiplexers ICs applications.

Ultrasound
Audio and video switching
Automatic test equipment
Precision data acquisition
Battery-powered systems
Sample-and-hold systems
Communication systems
Data Acquisition Systems
Relay Replacement
Battery Powered Systems
