ADI DG301AC/D

Manufacturer No:

DG301AC/D

Manufacturer:

ADI

Package:

Description:

12 Terminations Signal switch 1 Functions

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

DG301AC/D information

ADI DG301AC/D technical specifications, attributes, parameters and parts with similar specifications to ADI DG301AC/D.

Type
Parameter

Factory Lead Time
10 Weeks

Surface Mount
YES

Packaging
Tray

Published
2008

JESD-609 Code
e0

Pbfree Code
no

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
12

ECCN Code
EAR99

Terminal Finish
TIN LEAD

HTS Code
8542.39.00.01

Subcategory
Multiplexer or Switches

Technology
CMOS

Terminal Position
UPPER

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
240

Number of Functions
1

Supply Voltage
15V

Reach Compliance Code
not_compliant

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Pin Count
14

JESD-30 Code
S-XUUC-N12

Qualification Status
Not Qualified

Supply Voltage-Max (Vsup)
18V

Power Supplies
+-15V

Temperature Grade
COMMERCIAL

Supply Voltage-Min (Vsup)
5V

Number of Channels
1

Analog IC - Other Type
SPDT

Neg Supply Voltage-Nom (Vsup)
-15V

On-State Resistance (Max)
50Ohm

Off-state Isolation-Nom
62 dB

Neg Supply Voltage-Max (Vsup)
-18V

Switching
BREAK-BEFORE-MAKE

Switch-on Time-Max
300ns

Switch-off Time-Max
250ns

Neg Supply Voltage-Min (Vsup)
-5V

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for ADI DG301AC/D.

ConflictMineralStatement:

maximintegrated-ds1075z66n-conflictmineralstatement-7504.pdf

DG301AC/D Overview

As a result, it is packaged in a way that is referred to as Tray.It is designed with 12 terminations as part of its basic configuration.For multiplexer's system, a voltage of 15V is supplied.This turn signal switch consists of 14 component pins.Using the point NO LEAD as an end point of conductors, it is used to determine the terminus of a conductor.To prevent unnecessary failures, it is recommended that the minimum supply voltage (Vsup) remain at 5V.In order to avoid unnecessary failures, the maximum supply voltage (Vsup) should be kept at 18V.During mux switch's normal operation, +-15V is provided with a power supply.This is an the digital switch ic that is classified as Multiplexer or Switches.A total of 1 transmission channels are available in the turn signal switch's circuit.In this case, 70°C is the maximum operating temperature of the switches.SPDT is employed as the analog IC in this digital switch.

DG301AC/D Features

Power supplies of +-15V
SPDT as the analog IC

DG301AC/D Applications

There are a lot of Maxim Integrated
DG301AC/D Signal Switches / Multiplexers / Decoders applications.

D/A converters
Implementing boolean functions with multiple variables
Data collection system
Audio transmission
Video transmission
Image transmission
Recording transmission
Combinational circuit
Logic gates for other digital devices
Signal router
