VISHAY DG201BDJ
VISHAY DG201BDJ

VISHAY DG201BDJ

Manufacturer No:

DG201BDJ

Manufacturer:

VISHAY

Package:

16-DIP (0.300, 7.62mm)

Description:

300ns, 200ns SPST - NC 85Ohm Analog Switches BREAK-BEFORE-MAKE 16 Pins 500pA 15V 16-DIP (0.300, 7.62mm)

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

DG201BDJ information

VISHAY DG201BDJ technical specifications, attributes, parameters and parts with similar specifications to VISHAY DG201BDJ.

  • Type
  • Parameter
  • Factory Lead Time
  • 6 Weeks
  • Mount
  • Through Hole
  • Mounting Type
  • Through Hole
  • Package / Case
  • 16-DIP (0.300, 7.62mm)
  • Number of Pins
  • 16
  • Weight
  • 1.627801g
  • Operating Temperature
  • -40°C~85°C TA
  • Packaging
  • Tube
  • Published
  • 2000
  • JESD-609 Code
  • e0
  • Pbfree Code
  • no
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 16
  • Resistance
  • 85Ohm
  • Terminal Finish
  • Tin/Lead (Sn/Pb)
  • Subcategory
  • Multiplexer or Switches
  • Max Power Dissipation
  • 470mW
  • Technology
  • CMOS
  • Number of Functions
  • 4
  • Supply Voltage
  • 15V
  • Output
  • SEPARATE OUTPUT
  • Pin Count
  • 16
  • Power Supplies
  • +-15V
  • Min Supply Voltage
  • 4.5V
  • Power Dissipation
  • 470mW
  • Max Supply Current
  • 50?A
  • Turn On Delay Time
  • 300 ns
  • Number of Inputs
  • 4
  • Voltage - Supply, Single/Dual (±)
  • 4.5V~25V ±4.5V~22V
  • Supply Type
  • Dual, Single
  • Neg Supply Voltage-Nom (Vsup)
  • -15V
  • Turn-Off Delay Time
  • 200 ns
  • Max Dual Supply Voltage
  • 22V
  • On-State Resistance (Max)
  • 85Ohm
  • Min Dual Supply Voltage
  • 4.5V
  • Multiplexer/Demultiplexer Circuit
  • 1:1
  • Current - Leakage (IS(off)) (Max)
  • 500pA
  • Channel Capacitance (CS(off), CD(off))
  • 5pF 5pF
  • Switch Circuit
  • SPST - NC
  • Switch Time (Ton, Toff) (Max)
  • 300ns, 200ns
  • Charge Injection
  • 1pC
  • Channel-to-Channel Matching (?Ron)
  • 2 ?
  • Crosstalk
  • -95dB @ 100kHz
  • Switching
  • BREAK-BEFORE-MAKE
  • Drain to Source Resistance
  • 85Ohm
  • Normal Position
  • NC

Download datasheets and manufacturer documentation for VISHAY DG201BDJ.

Datasheets:

RohsStatement:

DG201BDJ Overview


Packed in 16-DIP (0.300, 7.62mm), the electronic component is convenient for shipping overseas. Advanced packaging method Tube is used to provide high reliability. This analog switch is mounted in Through Hole. The ratio between the number of multiplexer and demultiplexer circuits is 1:1. Extended operating temperature around -40°C~85°C TA. There are 16 terminations totally. With a 15V voltage supply, the electrical component should be turned on and run. 16 pins are injected to the electronic part body. These analog multiplexers are built based on SPST - NC switching circuits. This digital multiplexer has 85Ohm internal resistance. Please refer to the datasheets for 16 pins functions. This switch device is a typical Multiplexer or Switches. In a normalsituation, users should not supply the switches with voltage higher than 25V. A cost-effective Dual, Single supply type analogue multiplexer. The lowest voltage fed to the electronic component should be 4.5V. If put voltage greater than 50?A on the device, damage may be caused to the analogue multiplexer. Dual supply volatge is feasible for this multiplexer. But it should not go beyond 22V. You should attach at least 4.5V voltage if you are using dual power supply. This analog switch ic utilizes SEPARATE OUTPUT output. The electrical component supports 4 inputs. This electronic component presents a Drain to Source resistance of 85Ohm.

DG201BDJ Features


Switch Circuit: SPST - NC
Drain-to-Source resistance: 85Ohm


DG201BDJ Applications


There are a lot of Vishay Siliconix
DG201BDJ Analog Switches & Multiplexers ICs applications.


  • High-Voltage
  • Transmit
  • Low-Voltage
  • Isolation
  • Medical
  • Imaging
  • Ultrasound
  • Audio and video switching
  • Automatic test equipment
  • Precision data acquisition
