INFINEON DD46S12K

Manufacturer No:

DD46S12K

Manufacturer:

INFINEON

Package:

Module

Description:

2-Element Module

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

DD46S12K information

INFINEON DD46S12K technical specifications, attributes, parameters and parts with similar specifications to INFINEON DD46S12K.

Type
Parameter

Mount
Panel

Package / Case
Module

Number of Pins
46

Diode Element Material
SILICON

Published
1999

Part Status
Active

Number of Terminations
3

Type
Discrete Semicondutor

Max Operating Temperature
150°C

Min Operating Temperature
-40°C

HTS Code
8541.10.00.80

Subcategory
Rectifier Diodes

Terminal Position
UPPER

Terminal Form
UNSPECIFIED

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Pin Count
3

JESD-30 Code
R-XUFM-X3

Qualification Status
Not Qualified

Number of Elements
2

Configuration
SERIES CONNECTED, CENTER TAP, 2 ELEMENTS

Current - Output
100A

Case Connection
ISOLATED

Forward Current
45A

Halogen Free
Not Halogen Free

Number of Phases
1

Peak Reverse Current
20mA

Max Repetitive Reverse Voltage (Vrrm)
1.2kV

Reverse Voltage
1.2kV

Max Forward Surge Current (Ifsm)
850A

Height
30mm

Length
92mm

Width
20mm

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for INFINEON DD46S12K.

Datasheets:

infineon-dd46s12k-datasheets-2055.pdf

ConflictMineralStatement:

infineon-b43821a4225m000-conflictmineralstatement-7662.pdf

DD46S12K Overview

There will be no operation of this device when the forward voltage is set to 45A.In devices such as this one, reverse voltage peak is set at 20mA.

DD46S12K Features

a peak voltage of 20mA
a reverse voltage peak of 20mA

DD46S12K Applications

There are a lot of Infineon
DD46S12K applications of rectifier diode array.

Rectifier for drives applications
Crowbar applications
Rectifiers for UBS
Battery chargers
Rectifiers in switch mode power supplies (SMPS)
Free wheeling diode in low voltage converters
General Rectification
