TI DAC8822QBDBTG4

Manufacturer No:

DAC8822QBDBTG4

Manufacturer:

Package:

TSSOP

Description:

DAC 2 B B 4.4mm mm

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

DAC8822QBDBTG4 information

TI DAC8822QBDBTG4 technical specifications, attributes, parameters and parts with similar specifications to TI DAC8822QBDBTG4.

Type
Parameter

Package / Case
TSSOP

Surface Mount
YES

Number of Pins
38

Packaging
Rail/Tube

JESD-609 Code
e4

Pbfree Code
yes

Moisture Sensitivity Level (MSL)
2 (1 Year)

Number of Terminations
38

Terminal Finish
Nickel/Palladium/Gold (Ni/Pd/Au)

Max Operating Temperature
125°C

Min Operating Temperature
-40°C

Subcategory
Other Converters

Terminal Position
DUAL

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Supply Voltage
5V

Terminal Pitch
0.5mm

Pin Count
38

Power Supplies
3/5V

Temperature Grade
AUTOMOTIVE

Interface
Parallel

Max Supply Voltage
5.5V

Min Supply Voltage
2.7V

Supply Current-Max
0.006mA

Converter Type
D/A CONVERTER

Supply Type
Single

Resolution
2 B

Sampling Rate
2 Msps

Settling Time
500 ns

Power Consumption
25?W

Linearity Error-Max (EL)
0.0031%

Integral Nonlinearity (INL)
2 LSB

Input Bit Code
BINARY

Number of Converters
2

Conversion Rate
2 Msps

Analog Output Voltage-Max
10V

Differential Nonlinearity
1 LSB

Analog Output Voltage-Min
-10V

Length
9.7mm

Width
4.4mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for TI DAC8822QBDBTG4.

DAC8822QBDBTG4 Overview

It is supplied in the TSSOP package. It is powered from a supply voltage of 5V. This FPGA part belongs to the family of Other Converters. This FPGA model is contained in Rail/Tube for space saving. It is designed with 38 terminations. It is designed with 38 pins. It operates from a 3/5V power supply. The maximal operating temperature of this module reaches 125°C. The operating temperature should be higher than -40°C. It is equipped with 38 pin count. It supports the maximal supply voltage of 5.5V. It is able to work with the minimal supply voltage of 2.7V.

DAC8822QBDBTG4 Features

TSSOP package
38 pin count
38 pins

DAC8822QBDBTG4 Applications

There are a lot of Texas Instruments
DAC8822QBDBTG4 Digital to Analog Converters (DAC) applications.

Audio Amplifier
Video Encoder
Display Electronics
Data Acquisition Systems
Calibration
Motor Control
Data Distribution System
Digital Potentiometer
Software Radio
Wireless infrastructure:
