Renesas DAC1653D1G5NLGA8

Manufacturer No:

DAC1653D1G5NLGA8

Manufacturer:

Renesas

Package:

Description:

DAC 2 B B 8mm mm

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

DAC1653D1G5NLGA8 information

Renesas DAC1653D1G5NLGA8 technical specifications, attributes, parameters and parts with similar specifications to Renesas DAC1653D1G5NLGA8.

Type
Parameter

Contact Plating
Tin

Mount
Surface Mount

Number of Pins
56

Packaging
Tape & Reel

Published
2012

JESD-609 Code
e3

Pbfree Code
yes

Part Status
Discontinued

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
56

ECCN Code
EAR99

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Terminal Position
QUAD

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Supply Voltage
1.2V

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Pin Count
56

Polarity
Unipolar

Temperature Grade
INDUSTRIAL

Interface
Serial

Min Supply Voltage
3.15V

Power Dissipation-Max
844mW

Operating Supply Current
123mA

Number of Bits
16

Converter Type
D/A CONVERTER

Differential Output
Yes

Resolution
2 B

Sampling Rate
1.5 Gsps

Settling Time
20 ?s

Conversion Rate
2 Gsps

Number of D/A Converters
2

Analog Output Voltage-Max
1V

Voltage Reference
700mV

Length
8mm

Height Seated (Max)
0.9mm

Width
8mm

Thickness
850?m

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Renesas DAC1653D1G5NLGA8.

Datasheets:

integrateddevicetechnology-dac1653d1g5nlga8-datasheets-3607.pdf

DAC1653D1G5NLGA8 Overview

Supply voltage is 1.2V volts. As a result of space limitations, this FPGA model has been included in Tape & Reel. In total, the terminations of this piece are 56. The device has 56 pins which are included in the design. I think, as long as this FPGA is mounted in Surface Mount, it could perform excellently according to its specifications as long as you mount it in Surface Mount. This module can reach a maximum operating temperature of 85°C when operating at its maximum power. It is necessary to maintain an operating temperature higher than -40°C. I am going to present you with a device that is equipped with 56 pins. The maximum supply voltage it can take is 3.45V. The device can function at a minimum voltage of 3.15V. There is a 123mA supply current used in its operation.

DAC1653D1G5NLGA8 Features

56 pin count
56 pins

DAC1653D1G5NLGA8 Applications

There are a lot of Integrated Device Technology (IDT)
DAC1653D1G5NLGA8 Digital to Analog Converters (DAC) applications.

Wireless infrastructure:
WCDMA, CDMA2000, TD-SCDMA, WiMAX
Wideband communications:
LMDS/MMDS, point-to-point
Instrumentation:
RF signal generators, arbitrary waveform generators
Mobile Communications
Process Control and Industrial Automation
Automatic Test Equipment
Portable Equipment
