Manufacturer No:

DA14580-01UNA

Manufacturer:

Renesas

Package:

34-UFBGA, WLCSP

Description:

TxRx + MCU 2.4GHz 2.35V~3.3V I2C, SPI, UART 3.4mA - Transmitting 32kB OTP 84kB ROM 50kB SRAM 14 34-UFBGA, WLCSP

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

DA14580-01UNA information

Renesas DA14580-01UNA technical specifications, attributes, parameters and parts with similar specifications to Renesas DA14580-01UNA.

  • Type
  • Parameter
  • Factory Lead Time
  • 12 Weeks
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 34-UFBGA, WLCSP
  • Number of Pins
  • 34
  • Operating Temperature
  • -40°C~85°C
  • Packaging
  • Cut Tape (CT)
  • Published
  • 2015
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 34
  • Type
  • TxRx + MCU
  • HTS Code
  • 8542.39.00.01
  • Voltage - Supply
  • 2.35V~3.3V
  • Terminal Position
  • BOTTOM
  • Terminal Form
  • BALL
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Number of Functions
  • 1
  • Supply Voltage
  • 1V
  • Terminal Pitch
  • 0.4mm
  • Frequency
  • 2.4GHz
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Operating Supply Voltage
  • 3.3V
  • Interface
  • I2C, SPI, UART
  • RAM Size
  • 50kB
  • Max Supply Current
  • 3.7mA
  • Protocol
  • Bluetooth v4.1
  • Power - Output
  • -1dBm
  • RF Family/Standard
  • Bluetooth
  • Serial Interfaces
  • I2C, SPI, UART
  • Current - Transmitting
  • 3.4mA
  • Sensitivity (dBm)
  • -93 dBm
  • GPIO
  • 14
  • Length
  • 2.436mm
  • Height Seated (Max)
  • 0.551mm
  • Width
  • 2.436mm
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for Renesas DA14580-01UNA.

DA14580-01UNA Overview


The 34-UFBGA, WLCSP package saves space on the board. The RF transceiver's mounting method adopted is Surface Mount.Initially, it emerges as a TxRx + MCU with transceiver RF's high efficiency and a high degree of reliability.In order to provide high reliability, advanced transceiver RF' packaging Cut Tape (CT) is used.There are 34 pins on this transceiver RF circuit board.The mount is attached to Surface Mount.This system operates at 2.4GHz frequency.

DA14580-01UNA Features


34-UFBGA, WLCSP package
Surface Mount for mounting
TxRx + MCU
Cut Tape (CT) is used
34 pins


DA14580-01UNA Applications


There are a lot of Dialog Semiconductor GmbH
DA14580-01UNA RF Transceiver ICs applications.


  • Chemical Sensors
  • Security Systems
  • M2M Communication
  • Remote Device Management
  • Low-power IoT applications
  • LoT applications
  • Power Amplifier (PA)
  • Low Noise Amplifier (LNA)
  • Transmit
  • Receive

User Guide
