OMRON D8M-D1

Manufacturer No:

D8M-D1

Manufacturer:

OMRON

Package:

3-SIP Module

Description:

Vented Gauge Pressure Sensor PWM -30°C~70°C 0.85PSI (5.88kPa) Barbless ±2% 2.2V~3.4V

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

D8M-D1 information

OMRON D8M-D1 technical specifications, attributes, parameters and parts with similar specifications to OMRON D8M-D1.

Type
Parameter

Package / Case
3-SIP Module

Surface Mount
NO

Mounting Feature
PANEL MOUNT

Number of Pins
3

Operating Temperature
-30°C~70°C

Published
2002

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
Not Applicable

Applications
Board Mount

Voltage - Rated DC
3.4V

Voltage - Supply
2.2V~3.4V

Reach Compliance Code
unknown

Termination Style
Cable

Output Type
PWM

Operating Supply Voltage
3.4V

Nominal Supply Current
25mA

Accuracy
±2%

Response Time
2500 ?s

Operating Pressure
0.85PSI (5.88kPa)

Pressure Type
Vented Gauge

Port Style
Barbless

Port Size
Male - 0.13 3.3mm Tube

Maximum Pressure
8.53PSI (58.8kPa)

Sensors/Transducers Type
PRESSURE SENSOR,CAPACITIVE

Max Pressure
8.53 PSI

Pressure Range-Max
0.85 Psi

Pressure Sensing Mode
GAGE

Height
12.4mm

Length
30mm

Width
30mm

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for OMRON D8M-D1.

Datasheets:

omronelectronicsincemcdiv-d8md1-datasheets-4943.pdf

omron-d8md1-datasheets-2860.pdf

omron-d8md1-datasheets-2861.pdf

D8M-D1 Overview

As a convenience, the transducer is included in package 3-SIP Module. Reliable performance is ensured by setting the transducer temperature to -30°C~70°C. With a voltage supply of 2.2V~3.4V, the transducers can function properly. There is a requirement for connecting the 3 pins to make the transducer work properly. This transducer can handle pressures up to 0.85 Psi. Transducers working with 25mA supply current can function normally. For the transducers to continuously work at the rated ambient temperature, DC voltage should be 3.4V.
