INTEL CP82C55A-5

Manufacturer No:

CP82C55A-5

Manufacturer:

INTEL

Package:

Description:

40 Termination 2.54mm 5V I/O Expander 5V

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

CP82C55A-5 information

INTEL CP82C55A-5 technical specifications, attributes, parameters and parts with similar specifications to INTEL CP82C55A-5.

Type
Parameter

Surface Mount
NO

Published
2016

JESD-609 Code
e0

Pbfree Code
no

Number of Terminations
40

ECCN Code
EAR99

Terminal Finish
Tin/Lead (Sn/Pb)

HTS Code
8542.39.00.01

Subcategory
Parallel IO Port

Technology
CMOS

Terminal Position
DUAL

Terminal Form
THROUGH-HOLE

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Supply Voltage
5V

Terminal Pitch
2.54mm

Reach Compliance Code
not_compliant

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Pin Count
40

JESD-30 Code
R-PDIP-T40

Qualification Status
Not Qualified

Operating Temperature (Max)
70°C

Supply Voltage-Max (Vsup)
5.5V

Power Supplies
5V

Temperature Grade
COMMERCIAL

Number of I/O
24

Number of Ports
3

uPs/uCs/Peripheral ICs Type
PARALLEL IO PORT, GENERAL PURPOSE

Supply Current-Max
5mA

Length
51.75mm

Height Seated (Max)
6.35mm

Width
15.24mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for INTEL CP82C55A-5.

ConflictMineralStatement:

intel-cnla6000pk5-conflictmineralstatement-0045.pdf

Datasheets:

intel-cp82c55a5-datasheets-0225.pdf

CP82C55A-5 Overview

With 24 I/Os, it can be programmed.Its terminations, as a whole, are in the 40 direction.Total pin count on the part is 40.Device 5V provides voltage.To run NOT SPECIFIED, we rely on this part's peak reflow temperature.A total of five 3 ports are available on the device.At 5V, the power can be delivered.ICs with PARALLEL IO PORT, GENERAL PURPOSE uPs/uCs/Peripheral Types are included.The Parallel IO Port series includes this model.
