Manufacturer No:

CBTL06GP213EEJ

Manufacturer:

NXP

Package:

50-TFBGA

Description:

50 Termination 0.5mm Analog Switch CBTL06GP 50-TFBGA

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

CBTL06GP213EEJ information

NXP CBTL06GP213EEJ technical specifications, attributes, parameters and parts with similar specifications to NXP CBTL06GP213EEJ.

  • Type
  • Parameter
  • Factory Lead Time
  • 7 Weeks
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 50-TFBGA
  • Surface Mount
  • YES
  • Operating Temperature
  • -40°C~105°C TA
  • Packaging
  • Tape & Reel (TR)
  • Published
  • 2010
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 50
  • Applications
  • DisplayPort, PCIe, Video
  • HTS Code
  • 8542.39.00.01
  • Terminal Position
  • BOTTOM
  • Terminal Form
  • BALL
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Number of Functions
  • 1
  • Terminal Pitch
  • 0.5mm
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Base Part Number
  • CBTL06GP
  • Pin Count
  • 50
  • JESD-30 Code
  • S-PBGA-B50
  • Number of Channels
  • 6
  • -3db Bandwidth
  • 9.5GHz
  • On-State Resistance (Max)
  • 10Ohm
  • Consumer IC Type
  • CONSUMER CIRCUIT
  • Voltage - Supply, Single (V+)
  • 3V~3.6V
  • Features
  • Bi-Directional, HDMI
  • Length
  • 5mm
  • Height Seated (Max)
  • 1.15mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for NXP CBTL06GP213EEJ.

Datasheets:

Environmental Information:

CBTL06GP213EEJ Overview


It is used in conjunction with the package Tape & Reel (TR).A Surface Mount mounting type is recommended for this part.As far as the device is concerned, it has 6 channels.This device is packaged in 50-TFBGA.With its features, it can be used in a wide range of applications, such as DisplayPort, PCIe, Video.Depending on the setting, the operating temperature at -40°C~105°C TA can be varied.50 terminations are located on the chip.To give you a better understanding of this part, it includes 1 functions.There is a base part number of CBTL06GP for this product.The sum of the IC chip pins is 50.
