INFINEON BTS3125TFATMA1

Manufacturer No:

BTS3125TFATMA1

Manufacturer:

INFINEON

Package:

TO-252-3, DPak (2 Leads + Tab), SC-63

Description:

N-Channel 2.28mm PMIC 5V TO-252-3, DPak (2 Leads + Tab), SC-63

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

BTS3125TFATMA1 information

INFINEON BTS3125TFATMA1 technical specifications, attributes, parameters and parts with similar specifications to INFINEON BTS3125TFATMA1.

Type
Parameter

Factory Lead Time
18 Weeks

Mounting Type
Surface Mount

Package / Case
TO-252-3, DPak (2 Leads + Tab), SC-63

Surface Mount
YES

Usage Level
Automotive grade

Operating Temperature
-40°C~150°C TJ

Packaging
Tape & Reel (TR)

Published
2017

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
2

ECCN Code
EAR99

Terminal Position
SINGLE

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Number of Functions
1

Supply Voltage
5V

Terminal Pitch
2.28mm

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

JESD-30 Code
R-PSSO-G2

Number of Outputs
1

Output Voltage
40V

Output Type
N-Channel

Interface
On/Off

Output Configuration
Low Side

Voltage - Supply (Vcc/Vdd)
Not Required

Input Type
Non-Inverting

Switch Type
General Purpose

Nominal Input Voltage
5.5V

Ratio - Input:Output
1:1

Voltage - Load
31V Max

Fault Protection
Current Limiting (Fixed), Over Temperature, Over Voltage

Output Peak Current Limit-Nom
2A

Rds On (Typ)
108m Ω

Built-in Protections
TRANSIENT; OVER CURRENT; OVER VOLTAGE; THERMAL

Output Current Flow Direction
SINK

Features
Auto Restart

Length
6.5mm

Height Seated (Max)
2.5mm

Width
6.22mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for INFINEON BTS3125TFATMA1.

BTS3125TFATMA1 Overview

The LED driver's packaged as a Tape & Reel (TR).The TO-252-3, DPak (2 Leads + Tab), SC-63 package contains it.Surface Mount is the mounting type of the LED driver.The switch type is General Purpose.To ensure reliable operation, the temperature should be set to -40°C~150°C TJ.There is a default setting of 1 for output.To operate, it needs a supply voltage of Not Required.The maximum output voltage is N-Channel volts.It contains 2 terminations.The LED driver has 1 functions.A supply voltage of 5V leads to high efficiency.In order for the lighting driver to operate normally, the supply voltage (Vsup) should be maintained above 3V.

BTS3125TFATMA1 Features

Supplied from 5V

BTS3125TFATMA1 Applications

There are a lot of Infineon Technologies
BTS3125TFATMA1 Power Switches ICs applications.

Portable GPS Device
Set-top-box
USB Power Distribution
Notebook PC
Telecom and Network Systems
PC Card Hot Swap
Storage Drives
Portable/Handheld Devices
Wireless/Networking Cards
Low Voltage I/O System Power
