TI BQ24304DSGR

Manufacturer No:

BQ24304DSGR

Manufacturer:

Package:

8-WFDFN Exposed Pad

Description:

3.3/30V 0°C~125°C TJ 1 Channel DUAL Battery Management ICs 4V BQ24304 8 Pins Lithium-Ion 8-WFDFN Exposed Pad

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

BQ24304DSGR information

TI BQ24304DSGR technical specifications, attributes, parameters and parts with similar specifications to TI BQ24304DSGR.

Type
Parameter

Contact Plating
Gold

Mounting Type
Surface Mount

Package / Case
8-WFDFN Exposed Pad

Surface Mount
YES

Number of Pins
8

Weight
10.886217mg

Operating Temperature
0°C~125°C TJ

Packaging
Tape & Reel (TR)

JESD-609 Code
e4

Pbfree Code
yes

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
2 (1 Year)

Number of Terminations
8

ECCN Code
EAR99

Subcategory
Power Management Circuits

Terminal Position
DUAL

Peak Reflow Temperature (Cel)
260

Supply Voltage
4V

Terminal Pitch
0.5mm

Base Part Number
BQ24304

Function
Battery Protection

Output Voltage
4.5V

Power Supplies
3.3/30V

Number of Channels
1

Min Supply Voltage
3.3V

Analog IC - Other Type
POWER SUPPLY SUPPORT CIRCUIT

Adjustable Threshold
NO

Supply Current-Max (Isup)
0.5mA

Fault Protection
Over Current, Over Temperature, Over/Under Voltage

Battery Chemistry
Lithium-Ion

Length
2mm

Width
2mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for TI BQ24304DSGR.

BQ24304DSGR Overview

The 8-WFDFN Exposed Pad package is appropriate for it. This power IC uses an analog IC called POWER SUPPLY SUPPORT CIRCUIT. Channels are available on 1. There are 8 pins on it. The smart tools battery is packaged in a Tape & Reel (TR) case. The minimum supply voltage for this electrical part should not be less than 3.3V volts. Power Management Circuits is the family name of this electrical component. Surface Mount is mounted in the way of this electronic component. It is recommended that the power IC's supply voltage not exceed 26V volts. The Battery Protection functions can be delivered by it. A temperature range of 0°C~125°C TJ is optimal for the electric part to deliver its performance. This electronic component includes Lithium-Ion in its battery chemistry. A 3.3/30V volt battery powers it. This battery management IC should always be set to 4V. Based on the BQ24304 family. It is not permitted to exceed 0.5mA for the maximum supply current (Isup).
