Manufacturer No:

BLUENRG-MSCSP

Manufacturer:

ST

Package:

34-XFBGA, WLCSP

Description:

TxRx + MCU 2.4GHz 1.7V~3.6V SPI 1Mbps 7.3mA~14.5mA - Receiving 5.8mA~28.8mA - Transmitting GFSK 64kB Flash 12kB RAM 34-XFBGA, WLCSP

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

BLUENRG-MSCSP information

ST BLUENRG-MSCSP technical specifications, attributes, parameters and parts with similar specifications to ST BLUENRG-MSCSP.

  • Type
  • Parameter
  • Lifecycle Status
  • ACTIVE (Last Updated: 7 months ago)
  • Factory Lead Time
  • 16 Weeks
  • Mount
  • Surface Mount
  • Package / Case
  • 34-XFBGA, WLCSP
  • Number of Pins
  • 34
  • Operating Temperature
  • -40°C~85°C
  • Packaging
  • Cut Tape (CT)
  • Series
  • BlueNRG
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 34
  • ECCN Code
  • 5A992.C
  • Type
  • TxRx + MCU
  • HTS Code
  • 8542.39.00.01
  • Voltage - Supply
  • 1.7V~3.6V
  • Terminal Position
  • BOTTOM
  • Terminal Form
  • BUTT
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Number of Functions
  • 1
  • Supply Voltage
  • 3V
  • Terminal Pitch
  • 0.4mm
  • Frequency
  • 2.4GHz
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Memory Size
  • 64kB Flash 12kB RAM
  • RAM Size
  • 12kB
  • Max Supply Current
  • 28.8mA
  • Protocol
  • Bluetooth v4.1
  • Power - Output
  • 8dBm
  • RF Family/Standard
  • Bluetooth
  • Data Rate (Max)
  • 1Mbps
  • Serial Interfaces
  • SPI
  • Current - Receiving
  • 7.3mA~14.5mA
  • Current - Transmitting
  • 5.8mA~28.8mA
  • Modulation
  • GFSK
  • Sensitivity (dBm)
  • -88 dBm
  • Length
  • 2.66mm
  • Height Seated (Max)
  • 0.5mm
  • Width
  • 2.56mm
  • REACH SVHC
  • No SVHC
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for ST BLUENRG-MSCSP.

Datasheets:

BLUENRG-MSCSP Overview


There is a 34-XFBGA, WLCSP package on the board that RF transceiver IC is used to save space. With transceiver RF's high efficiency and reliable performance, it emerges as a TxRx + MCU.A high level of reliability is provided by using an advanced transceiver RF' packaging Cut Tape (CT).34 pins are provided on the transceiver RF circuit board.The mount is provided by Surface Mount.As the name implies, this RF transceiver is a kind of the famous BlueNRG series product line.In the 2.4GHz frequency range, RF transceiver operates .

BLUENRG-MSCSP Features


34-XFBGA, WLCSP package
TxRx + MCU
Cut Tape (CT) is used
34 pins
BlueNRG series


BLUENRG-MSCSP Applications


There are a lot of STMicroelectronics
BLUENRG-MSCSP RF Transceiver ICs applications.
