ROHM BD9639MWV-E2

Manufacturer No:

BD9639MWV-E2

Manufacturer:

ROHM

Package:

Description:

NOT SPECIFIED Cel QUAD Specialized Voltage Regulator 56 Pins 1.5MHz 56 Terminations

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

BD9639MWV-E2 information

ROHM BD9639MWV-E2 technical specifications, attributes, parameters and parts with similar specifications to ROHM BD9639MWV-E2.

Type
Parameter

Factory Lead Time
9 Weeks

Mount
Surface Mount

Packaging
Tape & Reel (TR)

Published
2011

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
56

ECCN Code
EAR99

Type
Integrated Circuit (IC)

Max Operating Temperature
85°C

Min Operating Temperature
-20°C

Additional Feature
ALSO HAS A CONTROL TECHNIQUE OF PFM

HTS Code
8542.39.00.01

Subcategory
Switching Regulator or Controllers

Technology
CMOS

Terminal Position
QUAD

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Number of Functions
1

Terminal Pitch
0.4mm

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Pin Count
56

Number of Outputs
6

Qualification Status
Not Qualified

Operating Supply Voltage
5.5V

Input Voltage-Nom
3.7V

Temperature Grade
OTHER

Min Supply Voltage
2.5V

Topology
Buck-Boost

Min Input Voltage
2.5V

Control Mode
VOLTAGE-MODE

Output Current-Max
2A

Max Input Voltage
5.5V

Control Technique
PULSE WIDTH MODULATION

Switching Frequency
1.5MHz

Length
7mm

Height Seated (Max)
1mm

Width
7mm

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for ROHM BD9639MWV-E2.

BD9639MWV-E2 Overview

Generally, it supports 6 outputs at a time. The power regulator is currently available in Tape & Reel (TR) packages. 56 terminals can be found on the electronic component. This alternator regulator has 56pins in its pinout. The PCB or other board can be mounted using the Surface Mount on it. In addition to these, there are other Switching Regulator or Controllers like the AC voltage regulator that play a significant role in the industry. Temperatures lower than -20°Care not suitable for it. There is no benefit to raising the temperature above 85°C. For normal operation, there should be 5.5V operating supply voltage applied. Refer to this voltage regulator's additional features as follows: ALSO HAS A CONTROL TECHNIQUE OF PFM. The input voltage for this alternator regulator must be greater than 2.5V. A frequency of 1.5MHzcan be set for the AC voltage regulator. The maximum output current of this electronic part is 2A. The power supply regulator allows a minimum supply voltage of 2.5V.
